| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (1270 670 H91) | FOURTH SPOOL CONTROL LEVER | -54 | F1 | |||
| ? | 1270 478 H91 | • BRACKET, CONTROL | 1 | ||||
| ? | 24 840 R1 | • BOLT, HEX - 3/8NCx1 | 3 | ||||
| ? | 25 534 R1 | • WASHER, FLAT - 3/8 | 6 | ||||
| ? | 25 522 R1 | • NUT, HEX - 3/8NC | 3 | ||||
| ? | 1270 473 H91 | • LEVER ASSY, FOURTH SPOOL | 1 | ||||
| ? | 1270 474 H91 | • • LEVER, FOURTH SPOOL | 1 | ||||
| ? | 173 892 C91 | • • BEARING, HANDLE | 2 | ||||
| ? | 264 055 R2 | • KNOB, HANDLE | 1 | ||||
| ? | 25 537 R1 | • WASHER, FLAT - 5/8 | 1 | ||||
| ? | 269 174 R1 | • RING, RETAINING | 1 | ||||
| ? | 117 175 | • FITTING, LUBE | 1 | ||||
| ? | 20 791 R1 | • PIN, CLEVIS - 1/4x29/32 | 1 | ||||
| ? | 25 532 R1 | • WASHER, FLAT - 1/4 | 1 | ||||
| ? | 103 362 | • PIN, COTTER - 1/16x3/4 | 1 | ||||
| ? | 1267 356 H1 | • LINK, SPOOL | 1 | ||||
| ? | 39 374 D | • PIN, CLEVIS - 5/16x7/8 | 1 | ||||
| ? | 103 373 | • PIN, COTTER - 3/32x3/4 | 1 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? |
