Номер на схеме	Каталожный номер	Название	Количество	Детали
?	421-22-30082	AXLE ASSEMBLY, FRONT	1	Code:
?	421-22-31084	• DIFFERENTIAL ASSEMBLY	1	Code:
?	421-22-37700	• • DIFFERENTIAL ASSEMBLY	1	Code:
?	421-22-37660	• • • CASE	1	Code:
?	421-22-37720	• • • COVER	1	Code:
?	175-21-12180	• • • PIN	4	Code:
?	01010-61240	• • • BOLT	18	Code:
?	01643-31232	• • • WASHER	18	Code:
?	421-22-37760	• • • RING, PRESSURE	2	Code:
?	421-22-37220	• • • SHAFT	1	Code:
?	421-22-37310	• • • PINION	4	Code:
?	421-22-37320	• • • GEAR	2	Code:
?	421-22-37410	• • • DISC	4	Code:
?	421-22-37450	• • • PLATE, T=3.1 MM	4	Code:
?	421-22-37460	• • • PLATE, T=3.2 MM	4	Code:
?	421-22-37371	• • • WASHER, T=4.0 MM	2	Code:
?	421-22-37381	• • • WASHER, T=4.1 MM	2	Code:
?	01010-61645	• • BOLT	20	Code:
?	01643-31645	• • WASHER	20	Code:
?	421-22-41860	• • BEARING	2	Code:
?	421-22-33811	• • HOUSING	1	Code:
?	421-22-31832	• • COVER, GEAR	1	Code:
?	01010-61225	• • BOLT	4	Code:
?	01643-31232	• • WASHER	4	Code:
