| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 419-01-21110 | BRACKET, TRANSMISSION MOUNT | 2 | SN: A30001-- |
|||
| ? | 01010-31650 | BOLT, MOUNT BRACKET | 8 | SN: A30001-- |
|||
| ? | 01643-31645 | WASHER | 8 | SN: A30001-- |
|||
| ? | 425-01-11350 | CUSHION, TRANSMISSION MOUNT | 4 | SN: A30001-- |
|||
| ? | 419-01-11162 | WASHER | 4 | SN: A30001-- |
|||
| ? | 01011-62230 | BOLT, MOUNT TRANSMISSION TO FRAME | 2 | SN: A30001-- |
|||
| ? | 01643-32260 | WASHER | 2 | SN: A30001-- |
|||
| ? | 01580-02218 | NUT | 2 | SN: A30001-- |
|||
| ? | 01016-51680 | BOLT, ADJUSTMENT | 4 | SN: A30001-- |
|||
| ? | 01580-01613 | NUT | 4 | SN: A30001-- |
|||
| ? | 419-01-11210 | BRACKET, LH - ENGINE MOUNT | 1 | SN: A30001-- |
|||
| ? | 419-01-11270 | SPACER | 1 | SN: A30001-- |
|||
| ? | 01010-81265 | BOLT, MOUNT BRACKET | 4 | SN: A30001-- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: A30001-- |
|||
| ? | 419-01-11221 | BRACKET, RH - ENGINE MOUNT | 1 | SN: A30001-- |
|||
| ? | 01010-81250 | BOLT, MOUNT BRACKET | 4 | SN: A30001-- |
|||
| ? | 01643-31232 | WASHER | 4 | SN: A30001-- |
|||
| ? | 418-01-11111 | CUSHION, ENGINE MOUNT | 2 | SN: A30001-- |
|||
| ? | 418-01-11120 | • CUSHION, TOP | 1 | SN: A30001-- |
|||
| ? | 418-01-11131 | • CUSHION, BOTTOM | 1 | SN: A30001-- |
|||
| ? | 419-01-11162 | WASHER | 4 | SN: A30001-- |
|||
| ? | 01011-62230 | BOLT, MOUNT ENGINE TO FRAME | 2 | SN: A30001-- |
|||
| ? | 01643-32260 | WASHER | 2 | SN: A30001-- |
|||
| ? | 01580-02218 | NUT | 2 | SN: A30001-- |
