| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6742-01-1230 | BOLT (M10-1.50x65) | 12 | ||||
| ? | 6742-01-1240 | CLAMP, RETAINING | 6 | ||||
| ? | 6742-01-1250 | ROD, PUSH | 12 | ||||
| ? | 6742-01-1260 | SUPPORT, ROCKER LEVER | 6 | ||||
| ? | 6742-01-1270 | LEVER ASSEMBLY, ROCKER | 12 | ||||
| ? | (NSS) | • LEVER, ROCKER | 1 | ||||
| ? | 6735-41-5550 | • NUT, HEAVY HEX (3/8-24 THD) | 1 | ||||
| ? | 6735-41-5560 | • SCREW, ADJUSTING | 1 | ||||
| ? | (NSS) | • INSERT, ROCKER LEVER | 1 | ||||
| ? | 6742-01-1290 | WASHER, SPRING | 12 | ||||
| ? | 6742-01-1300 | SHAFT ASSEMBLY, ROCKER LEVER | 6 | ||||
| ? | (NSS) | • SHAFT, ROCKER LEVER | 1 | ||||
| ? | 6732-41-5150 | • RIVET | 1 | ||||
| ? | 6742-01-1310 | WASHER, PLAIN (M22) | 12 | ||||
| ? | 6742-01-1320 | MANIFOLD, OIL | 1 | ||||
| ? | 6742-01-1330 | RING, RETAINING | 12 |
