Номер на схеме	Каталожный номер	Название	Количество
?	6742-01-1570	CRANKSHAFT ASSEMBLY	1
?	(NSS)	• CRANKSHAFT	1
?	6742-01-1590	• PIN, DOWEL	1
?	6732-21-6150	• GEAR, CRANKSHAFT	1
?	6742-01-5199	KIT, MAIN BEARING - STANDARD	1
?	(NSS)	• BEARING, MAIN UPPER	6
?	6742-01-5282	• BEARING, MAIN THRUST	1
?	(NSS)	• BEARING, MAIN LOWER	7
?	6742-01-5233	KIT, MAIN BEARING - 0.25MM OVERSIZE	1
?	(NSS)	• BEARING, MAIN UPPER	6
?	(NSS)	• BEARING, MAIN THRUST	1
?	(NSS)	• BEARING MAIN LOWER	7
?	6742-01-5240	KIT, MAIN BEARING - 0.50MM OVERSIZE	1
?	(NSS)	• BEARING, MAIN UPPER	6
?	6742-01-5284	• BEARING, MAIN THRUST	1
?	(NSS)	• BEARING, MAIN LOWER	7
?	6742-01-5287	KIT, MAIN BEARING - 0.75MM OVERSIZE	1
?	(NSS)	• BEARING, MAIN UPPER	6
?	6742-01-5285	• BEARING, MAIN THRUST	1
?	(NSS)	• BEARING, MAIN LOWER	7
?	6742-01-5288	KIT, MAIN BEARING - 1.00MM OVERSIZE	1
?	(NSS)	• BEARING, MAIN UPPER	6
?	6742-01-5286	• BEARING, MAIN THRUST	1
?	(NSS)	• BEARING, MAIN LOWER	7
?	1295 465 H92	SLEEVE, WEAR - FRONT CRANK	1
?	6736-39-1130	SLEEVE, WEAR - REAR CRANK	1
?
?		OVERSIZE THRUST BEARINGS
?
?	6742-01-5273	BEARING, CRANKSHAFT THRUST - STD JOURNAL
?		DIA. 0.25MM OVERSIZE THRUST FACE	1
?	6742-01-5274	BEARING, CRANKSHAFT THRUST - STD JOURNAL
?		DIA. 0.50MM OVERSIZE THRUST FACE	1
?	6742-01-5275	BEARING, CRANKSHAFT THRUST - 0.50MM
?		OVERSIZE JOURNAL DIA. 0.50MM OVERSIZE THRUST FACE	1
?
