| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6742-01-1001 | GASKET, OIL SUCTION CONNECTION | 1 | ||||
| ? | 6742-01-2620 | CONNECTION, OIL SUCTION | 1 | ||||
| ? | 6742-01-2630 | BOLT (M6-1.00x30) | 2 | ||||
| ? | 6742-01-0310 | SPACER, MOUNTING | 2 | ||||
| ? | 1241 280 H2 | BRACE, TUBE | 1 | ||||
| ? | 6732-21-4180 | BOLT (M6-1.00x15) | 2 | ||||
| ? | 6732-21-5180 | WASHER, PLAIN (M9) | 32 | ||||
| ? | 6742-01-2660 | NUT | 1 | ||||
| ? | 6742-01-5308 | GASKET, OIL PAN | 1 | ||||
| ? | 6742-01-2670 | PAN, OIL | 1 | ||||
| ? | 6735-21-5540 | BOLT (M8-1.25x21) | 16 | ||||
| ? | 6732-21-6610 | BOLT (M8-1.25x25) | 16 | ||||
| ? | 6732-21-5190 | WASHER, SPRING | 1 | ||||
| ? | 6732-21-5210 | PLUG, THREADED (M8-1.25x12) | 1 | ||||
| ? | 6742-01-2690 | WASHER, PLAIN (M6) | 1 | ||||
| ? | 6732-21-5540 | PLUG, PIPE (3/8 NPT) | 1 | ||||
| ? | 6736-21-5320 | PLUG, THREADED | 1 | ||||
| ? | 6732-21-5170 | WASHER, SEALING | 1 | ||||
| ? | 6735-71-5190 | BOLT (M6-1.0x20) | 1 | ||||
| ? | 6736-22-5210 | PLATE, CLAMPING | 4 |
