| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 419-01-A1310 | PRE-CLEANER, TURBO II | 1 | ||||
| ? | 419-01-A1410 | • NUT | 1 | ||||
| ? | 419-01-A1420 | • COVER | 1 | ||||
| ? | 419-01-A1430 | • STUD | 1 | ||||
| ? | 419-01-A1440 | • SCREEN | 1 | ||||
| ? | 419-01-A1450 | • BODY | 1 | ||||
| ? | 419-01-A1480 | • BOLT | 4 | ||||
| ? | 419-01-A1460 | • WASHER | 1 | ||||
| ? | 419-01-A1470 | • ROTOR | 1 | ||||
| ? | 419-01-A1490 | • BASE | 1 | ||||
| ? | 419-01-A1510 | • SPACER | 4 | ||||
| ? | 690 064 C1 | • CLAMP | 1 | ||||
| ? | 419-01-A1520 | • DECAL, TURBO II | 1 |
