| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 419-01-A1130 | AIR CLEANER ASSEMBLY | 1 | ||||
| ? | 419-02-11240 | • ELEMENT, AIR CLEANER (PRIMARY) | 1 | ||||
| ? | 419-02-11230 | • ELEMENT, AIR CLEANER (SAFETY) | 1 | ||||
| ? | 419-02-11250 | • COVER, AIR CLEANER | 1 | ||||
| ? | 6001-81-9671 | • NUT | 1 | ||||
| ? | 6001-81-9511 | • GASKET | 1 | ||||
| ? | 419-02-11260 | • GASKET, AIR CLEANER COVER | 1 | ||||
| ? | 600-181-1970 | • CLIP | 1 | ||||
| ? | 600-181-1950 | • NUT, WING | 1 | ||||
| ? | 600-181-4440 | • GASKET | 1 | ||||
| ? | 600-181-1370 | • VALVE, VACUATOR | 1 | ||||
| ? | 600-181-1960 | • NUT, COVER WING | 1 | ||||
| ? | 419-02-11220 | • BODY | 1 | ||||
| ? | 6222-81-7190 | BAND ASSEMBLY | 2 | ||||
| ? | 6643-11-4620 | • PIN | 1 | ||||
| ? | 6643-11-4630 | • PIN W/THREAD | 1 | ||||
| ? | 421-02-A1130 | BOLT | 2 | ||||
| ? | 600-181-3890 | CAP, SCREEN | 1 | ||||
| ? | 600-815-7940 | INDICATOR, DUST | 1 | ||||
| ? | 419-01-22151 | HOSE | 1 | ||||
| ? | 690 064 C1 | CLAMP | 1 | ||||
| ? | 1252 151 H1 | CLAMP | 1 | ||||
| ? | 419-01-A1170 | SUPPORT | 1 | ||||
| ? | 427-62-15060 | BOLT | 2 | ||||
| ? | 01643-31232 | WASHER | 2 | ||||
| ? | 01010-81030 | BOLT | 2 | ||||
| ? | 25 553 R1 | WASHER | 2 | ||||
| ? | 419-01-A1180 | SUPPORT | 1 | ||||
| ? | 01010-81030 | BOLT | 4 | ||||
| ? | 01643-31032 | WASHER | 4 |
