| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 423-01-A1120 | CLEANER ASSEMBLY, AIR | 1 | ||||
| ? | 600-181-1660 | • ELEMENT ASSEMBLY, PRIMARY FILTER | 1 | ||||
| ? | 600-181-1580 | • • ELEMENT, PRIMARY FILTER | 1 | ||||
| ? | 619 403 C1 | • • WASHER, SEAL | 1 | ||||
| ? | 1287 323 H1 | • • NUT, WING | 1 | ||||
| ? | 600-181-1680 | • ELEMENT, SAFETY FILTER | 1 | ||||
| ? | (NSS) | • COVER, END | 1 | ||||
| ? | (NSS) | • NUT | 1 | ||||
| ? | (NSS) | • SEAL | 1 | ||||
| ? | (NSS) | • GASKET, END COVER | 1 | ||||
| ? | (NSS) | • CLIP | 1 | ||||
| ? | (NSS) | • VALVE, VACUATOR | 1 | ||||
| ? | (NSS) | • NUT, COVER WING | 1 | ||||
| ? | (NSS) | • BODY | 1 |
