| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-43-22750 | TUBE | 1 | ||||
| ? | 421-09-12770 | UNION | 1 | ||||
| ? | 07002-12034 | O-RING | 1 | ||||
| ? | 07108-20406 | HOSE | 1 | ||||
| ? | 421-43-22970 | TUBE | 1 | ||||
| ? | 421-43-22430 | ELBOW | 1 | ||||
| ? | 07238-10628 | CONNECTOR | 1 | ||||
| ? | 07002-12434 | O-RING | 1 | ||||
| ? | 07108-20604 | HOSE | 1 | ||||
| ? | 421-43-23310 | JOINT | 1 | ||||
| ? | 01435-01020 | BOLT | 2 | ||||
| ? | 07108-20603 | HOSE | 1 | ||||
| ? | 423-62-23290 | TUBE | 1 | ||||
| ? | 07235-50628 | ELBOW | 1 | ||||
| ? | 07002-12434 | O-RING | 1 | ||||
| ? | 07042-30108 | PLUG | 1 | ||||
| ? | 07000-13025 | O-RING | 1 | ||||
| ? | 01435-01030 | BOLT | 2 | ||||
| ? | 421-43-22980 | BRACKET | 1 | ||||
| ? | 01435-01020 | BOLT | 2 | ||||
| ? | 07283-22738 | U-BOLT | 1 | ||||
| ? | 01643-31032 | WASHER | 2 | ||||
| ? | 01597-01009 | NUT | 2 | ||||
| ? | 425-03-11420 | BRACKET | 1 | ||||
| ? | 04434-52110 | CLIP | 1 | ||||
| ? | 01435-01016 | BOLT | 2 | ||||
| ? | 361-18-21430 | PROTECTOR | 1 |
