Номер на схеме	Каталожный номер	Название	Количество
?	423-43-27360	BRACKET	1
?	417-54-13470	SPACER	4
?	419-43-17930	CUSHION	4
?	415-64-13130	CUSHION	4
?	415-64-13120	WASHER	8
?	01435-01240	BOLT	4
?	423-43-27370	PLATE	1
?	01435-01220	BOLT	2
?	421-43-22360	CLAMP	4
?	01643-31232	WASHER	12
?	421-40-12440	NUT	12
?	423-43-27470	TUBE	1
?	01010-51050	BOLT	1
?	01643-31032	WASHER	1
?	423-43-27460	CONNECTOR	1
?	07002-11423	O-RING	1
?	421-43-22951	VALVE ASSEMBLY, CHECK	2
?	(NSS)	• BODY	1
?	(NSS)	• POPPET	1
?	419-43-27590	• SPRING	1
?	205-60-51420	• SEAT	1
?	04065-01410	• RING	1
?	07325-30300	NIPPLE	2
?	423-43-27420	HOSE	1
?	423-43-27430	HOSE	1
?	421-09-12730	CONNECTOR	2
?	07230-20422	UNION	1
?	07002-12034	O-RING	1
?	421-43-22370	TEE	1
?	07002-12034	O-RING	1
?	423-43-27450	CROSS	1
?	07002-12034	O-RING	1
?	421-43-22910	SWITCH, LOW PRESSURE	1
?	421-43-22920	SWITCH, EMERGENCY BRAKE	1
?	07002-11423	O-RING	2
?	07040-11409	PLUG	1
?	07002-11423	O-RING	1
?	423-43-27440	CROSS	1
?	07002-12034	O-RING	1
?	421-43-22910	SWITCH, LOW PRESSURE	1
?	421-43-22920	SWITCH, EMERGENCY BRAKE	1
?	07002-11423	O-RING	2
?	07108-20204	HOSE	1
?	07235-10210	ELBOW	2
?	07002-11423	O-RING	2
?	419-43-27330	ELBOW	1
?	07002-11423	O-RING	1
?	08034-20536	STRAP, TIE	1
?		HOSE (SEE PG 03-042)	-29	03-042
