Номер на схеме	Каталожный номер	Название	Количество
?	08088-30000	RELAY, STARTING MOTOR	1
?	01220-40408	• SCREW	2
?	01601-20410	• WASHER, SPRING	2
?	01220-40420	• SCREW	2
?	01601-20410	• WASHER, SPRING	2
?	419-06-21110	BRACKET	1
?	08037-02512	GROMMET	1
?	01435-00830	BOLT	2
?	01435-01020	BOLT	2
?	421-06-22880	HOLDER	2
?	421-06-22990	• BOLT, WITH WASHER	4
?	421-06-22820	FUSE, 80A - SLOW BLOW	1
?	417-06-22610	FUSE, 50A - SLOW BLOW	1
?	421-06-22840	FUSE, 30A - SLOW BLOW	1
?	421-06-22910	BRACKET	2
?	421-06-22920	BRACKET	2
?	01435-00816	BOLT	2
?	01643-30823	WASHER	2
?	424-06-12520	WIRE, BATTERY TO BATTERY	1
?	08028-45060	WIRE, GROUND - BATTERY	1
?	424-06-12840	WIRE, BATTERY TO RELAY	1
?	424-09-12530	BOOT	2
?	424-09-12540	BOOT	2
?	01010-51016	BOLT	1
?	01643-31032	WASHER	1
?	419-06-22240	WIRE, RELAY TO STARTING MOTOR	1
?	421-06-22410	WIRE, RELAY TO FUSE	1
?	419-06-A1290	WIRE, RELAY TO FUSE	1
?	08038-00035	CAP	3
?	419-06-22250	WIRE, GROUND - STARTING MOTOR	1
?	01010-51220	BOLT	1
?	01643-31032	WASHER	1
?	08036-01814	CLIP	5
