| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 423-03-21200 | RADIATOR ASSEMBLY | 1 | ||||
| ? | 423-03-21111 | • CORE, RADIATOR | 1 | ||||
| ? | 23S-03-11150 | • CAP, RADIATOR | 1 | ||||
| ? | 423-03-21120 | • FRAME | 1 | ||||
| ? | 421-03-11470 | • SHEET | 1 | ||||
| ? | 423-03-11150 | • CLAMP | 2 | ||||
| ? | 01010-50820 | • BOLT | 12 | ||||
| ? | 01602-20825 | • WASHER, SPRING | 12 | ||||
| ? | 424-03-11160 | • SHIM, 0.6mm | 26 | ||||
| ? | 423-03-21210 | • SHROUD | 1 | ||||
| ? | 01010-51016 | • BOLT | 8 | ||||
| ? | 01643-31032 | • WASHER | 8 | ||||
| ? | 421-03-11211 | • PACKING | 2 | ||||
| ? | 7861-92-4500 | SENSOR, COOLANT LEVEL | 1 | ||||
| ? | 07002-23634 | O-RING | 1 | ||||
| ? | 08053-01510 | CLIP | 1 | ||||
| ? | 01435-01016 | BOLT | 1 | ||||
| ? | 419-03-A1110 | GUARD, ENGINE FAN | 2 | ||||
| ? | 01010-51020 | BOLT | 8 | ||||
| ? | 25 553 R1 | WASHER | 8 | ||||
| ? | 416-03-11420 | BAR, MOUNTING | 2 | ||||
| ? | 01435-00812 | BOLT | 4 | ||||
| ? | 01010-51445 | BOLT | 2 | ||||
| ? | 01643-31445 | WASHER | 2 | ||||
| ? | 421-03-23150 | STAY | 2 | ||||
| ? | 01435-01235 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 2 | ||||
| ? | 423-03-23160 | COVER | 1 | ||||
| ? | 01435-01225 | BOLT | 4 | ||||
| ? | 423-03-23140 | PLATE, L.H | 1 | ||||
| ? | 423-03-23150 | PLATE, R.H | 1 | ||||
| ? | 421-03-23190 | SEAL | 1 | ||||
| ? | 423-03-23180 | SEAL | 2 |
