| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-57-21510 | SEAT, SUSPENSION TYPE | 1 | ||||
| ? | BS162663 | • UPPER ASSEMBLY, FABRIC | 1 | ||||
| ? | (NSS) | • • FRAME KIT, SEAT | 1 | F1 | |||
| ? | (NSS) | • • COVER, BACK | 1 | ||||
| ? | (NSS) | • • FOAM, BACK | 1 | ||||
| ? | (NSS) | • • COVER, SEAT | 1 | ||||
| ? | (NSS) | • • FOAM, SEAT | 1 | ||||
| ? | BS163369 | • HEIGHT RISER ASSEMBLY KIT | 1 | F1 | |||
| ? | BS163368 | • LATCH KIT, HEIGHT RISER | 1 | F1 | |||
| ? | BS162056 | • SPRING KIT, HEIGHT RISER | 1 | F1 | |||
| ? | BS164188 | • HANDLE KIT | 1 | F1 | |||
| ? | BS162032 | • ADJUSTMENT KIT, CABLE | 1 | F1 | |||
| ? | BS157230 | • SUSPENSION ASSEMBLY | 1 | ||||
| ? | BS156717 | • • STOP KIT, BUMP / UP | 1 | F1 | |||
| ? | BS156737 | • • ADJUSTMENT KIT, WEIGHT | 1 | F1 | |||
| ? | BS156738 | • • BEARING KIT, SUSPENSION | 1 | F1 | |||
| ? | BS157228 | • • DAMPER KIT | 1 | F1 | |||
| ? | BS162035 | • ADJUSTMENT KIT, SLIDERAIL (FORWARD/BACKWARD) | 1 | F1 | |||
| ? | BS152879 | • HANDLE, SLIDERAIL | 1 | ||||
| ? | BS151185 | • HEADREST KIT | 1 | F1 | |||
| ? | BS165216 | • ARMREST KIT, LH | 1 | F1 | |||
| ? | BS166386 | • ARMREST KIT, RH | 1 | F1 | |||
| ? | |||||||
| ? | F1 - ALL KITS HAVE REQUIRED MOUNTING HARDWARE. | ||||||
| ? |
