| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 423-54-21130 | DOOR, L.H. - SIDE PANEL | 1 | F1 | |||
| ? | 423-54-21630 | DOOR, L.H. - SIDE PANEL | 1 | F2 | |||
| ? | 423-54-21140 | DOOR, R.H. - SIDE PANEL | 1 | F1 | |||
| ? | 423-54-21640 | DOOR, R.H. - SIDE PANEL | 1 | F2 | |||
| ? | 01435-01225 | BOLT | 16 | ||||
| ? | 423-54-A1410 | PLATE, L.H | 1 | ||||
| ? | 423-54-A1410 | PLATE, R.H | 1 | ||||
| ? | 01010-81225 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 421-54-21990 | PLATE | 2 | ||||
| ? | 421-54-21980 | PLATE | 2 | ||||
| ? | 01641-21016 | WASHER | 6 | ||||
| ? | 04205-31022 | PIN | 4 | ||||
| ? | 04052-11038 | PIN, SNAP | 6 | ||||
| ? | 423-54-24650 | BELLCRANK | 2 | ||||
| ? | 423-54-24610 | ROD, L.H | 1 | ||||
| ? | 423-54-24620 | ROD, R.H | 1 | ||||
| ? | 423-54-24630 | ROD, L.H | 1 | ||||
| ? | 423-54-24640 | ROD, R.H | 1 | ||||
| ? | 417-54-21650 | STRIKER | 2 | ||||
| ? | 417-54-21610 | SPRING, L.H | 1 | ||||
| ? | 417-54-21660 | SPRING, R.H | 1 | ||||
| ? | 01641-21016 | WASHER | 4 | ||||
| ? | 01641-20608 | WASHER | 16 | ||||
| ? | 04050-13020 | PIN, SNAP | 4 | ||||
| ? | 04052-10633 | PIN, SNAP | 8 | ||||
| ? | 04050-11612 | PIN, COTTER | 8 | ||||
| ? | 423-54-24410 | SPRING, GAS | 4 | ||||
| ? | 04205-30832 | PIN | 4 | ||||
| ? | 01641-20812 | WASHER | 8 | ||||
| ? | 04052-10833 | PIN, SNAP | 8 | ||||
| ? | 419-54-21490 | PLATE | 2 | ||||
| ? | 01010-81225 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | |||||||
| ? | F1 - USED ON MACHINES NOT EQUIPPED WITH FULL REAR FENDERS. | ||||||
| ? | |||||||
| ? | F2 - USED ON MACHINES EQUIPPED WITH FULL REAR FENDERS. | ||||||
| ? |
