| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PEDAL ASSEMBLY, ACCELERATOR (SEE PG 01-028) | -29 | 01-028 | ||||
| ? | 01435-00620 | BOLT | 3 | ||||
| ? | 418-43-11140 | CABLE, THROTTLE | 1 | ||||
| ? | 04210-20624 | YOKE | 1 | ||||
| ? | 04205-10620 | PIN | 1 | ||||
| ? | 04050-11612 | PIN, COTTER | 1 | ||||
| ? | 04256-40615 | JOINT | 1 | ||||
| ? | 01643-30623 | WASHER | 1 | ||||
| ? | 01596-00606 | NUT | 1 | ||||
| ? | PUMP, FUEL INJECTION (SEE PG ) | -29 | |||||
| ? | 08036-01214 | CLIP | 2 | ||||
| ? | 01435-01220 | BOLT | 1 | ||||
| ? | 423-01-A1170 | BRACKET | 1 | ||||
| ? | 01010-51025 | BOLT | 2 | ||||
| ? | 01643-31032 | WASHER | 2 | ||||
| ? | 424-43-11240 | CUSHION | 2 | ||||
| ? | 01584-00605 | NUT | 4 | ||||
| ? | 423-43-11551 | PLATE | 1 | ||||
| ? | 419-43-21410 | PLATE | 1 |
