| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 423-57-A1120 | SUSPENSION ASSEMBLY | 1 | ||||
| ? | (NSS) | • ADJUSTER, SEAT | 1 | ||||
| ? | (NSS) | • PIN, ROLL | 1 | ||||
| ? | (NSS) | • PAD, SPRING | 1 | ||||
| ? | 423-57-A1210 | • SPRING CONICAL | 1 | ||||
| ? | (NSS) | • WASHER, SPRING | 1 | ||||
| ? | (NSS) | • GEAR AND SHAFT, VERTICAL | 1 | ||||
| ? | (NSS) | • PIN, ROLL | 1 | F5 | |||
| ? | (NSS) | • GEAR AND SHAFT, HORIZONTAL | 1 | ||||
| ? | (NSS) | • BRACKET, SHAFT | 1 | ||||
| ? | (NSS) | • ARM, SUSPENSION | 1 | ||||
| ? | (NSS) | • KNOB, WEIGHT ADJUSTMENT | 1 | F5 | |||
| ? | (NSS) | • PRODUCT GRAPHIC, INSTRUCTION | 1 | ||||
| ? | (NSS) | • BUSHING, TUBE | 4 | F1 | |||
| ? | (NSS) | • BOOT, SUSPENSION | 1 | F3 | |||
| ? | (NSS) | • FASTENER, PUSH ON | 23 | F3 | |||
| ? | (NSS) | • WASHER, THRUST | 1 | ||||
| ? | (NSS) | • BUMPER, SLIDER | 1 | F1 | |||
| ? | (NSS) | • BUMPER, SLIDER | 1 | F1 | |||
| ? | (NSS) | • BUMPER, SLIDER | 1 | F1 | |||
| ? | (NSS) | • BUMPER, SLIDER | 1 | F1 | |||
| ? | (NSS) | • ABSORBER, SHOCK | 1 | F4 | |||
| ? | (NSS) | • BUSHING, SHOCK ABSORBER | 2 | F4 | |||
| ? | (NSS) | • BOLT, SHOULDER | 1 | ||||
| ? | (NSS) | • NUT, LOCK | 1 | ||||
| ? | (NSS) | • BUMPER, SLIDE | 2 | ||||
| ? | (NSS) | • INDICATOR, RIDE | 1 | F1 | |||
| ? | (NSS) | • SHAFT, MOUNTING | 2 | ||||
| ? | (NSS) | • NUT, LOCK | 2 | ||||
| ? | (NSS) | • PIN, ROLL | 1 | ||||
| ? | (NSS) | • BOLT, CARRIAGE | 2 | ||||
| ? | (NSS) | • NUT, LOCK | 2 | ||||
| ? | (NSS) | • HOUSING, UPPER | 1 | ||||
| ? | (NSS) | • LINK | 2 | ||||
| ? | (NSS) | • LEVER, HEIGHT ADJUSTMENT | 1 | ||||
| ? | (NSS) | • SPRING | 1 | F2 | |||
| ? | (NSS) | • BOLT, 1/2NC X 1 - SHOULDER | 4 | ||||
| ? | (NSS) | • LINK, CONNECTING | 2 | ||||
| ? | (NSS) | • LATCH ASSEMBLY | 1 | ||||
| ? | (NSS) | • PIN, COIL SPRING - 5/32 X 3/4 | 1 | ||||
| ? | (NSS) | • SPRING | 2 | F2 | |||
| ? | (NSS) | • CAP HEIGHT ADJUSTMENT | 1 | ||||
| ? | 423-57-A1130 | • BEARING KIT | 1 | ||||
| ? | 423-57-A1220 | • SPRING KIT | 1 | ||||
| ? | 423-57-A1250 | • BOOT KIT | 1 | ||||
| ? | 423-57-A1270 | • SHOCK KIT | 1 | ||||
| ? | 423-57-A1310 | • ADJUSTMENT KNOB KIT | 1 | ||||
| ? | 423-57-A1330 | • BEARING KIT | 1 | ||||
| ? | |||||||
| ? | F1 - ORDER BEARING KIT 423-57-A1130 | ||||||
| ? | |||||||
| ? | F2 - ORDER SPRING KIT 423-57-A1220 | ||||||
| ? | |||||||
| ? | F3 - ORDER BOOT KIT 423-57-A1250 | ||||||
| ? | |||||||
| ? | F4 - ORDER SHOCK KIT 423-57-A1270 | ||||||
| ? | |||||||
| ? | F5 - ORDER ADJ. KNOB KIT 423-57-A1310 | ||||||
| ? | |||||||
| ? | F6 - ORDER BEARING KIT 423-57-A1330 | ||||||
| ? |
