| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 423-57-11104 | SEAT ASSEMBLY, OPERATOR'S | 1 | F1 | |||
| ? | 423-57-11303 | • SEAT ASSEMBLY | 1 | ||||
| ? | 423-57-11320 | • • CUSHION, BACK | 1 | ||||
| ? | 423-57-11490 | • • • BRACKET | 1 | ||||
| ? | 423-57-11380 | • • • BOLT | 2 | ||||
| ? | 423-57-11310 | • • CUSHION, SEAT | 1 | ||||
| ? | 423-57-11650 | • • • SPRING | 1 | ||||
| ? | 423-57-11450 | • • • BRACKET | 1 | ||||
| ? | 423-57-11380 | • • • BOLT | 2 | ||||
| ? | 423-57-11470 | • • • BRACKET, L.H | 1 | ||||
| ? | 423-57-11480 | • • • BRACKET, R.H | 1 | ||||
| ? | 423-57-11460 | • • • BOLT | 4 | ||||
| ? | 423-57-11420 | • • BUSHING | 1 | ||||
| ? | 423-57-11430 | • • SCREW | 1 | ||||
| ? | 423-57-11440 | • • WASHER | 1 | ||||
| ? | 423-57-11330 | • • RECLINING ASSEMBLY | 1 | ||||
| ? | 423-57-11380 | • • BOLT | 4 | ||||
| ? | 423-57-11371 | • • COVER | 1 | ||||
| ? | 423-57-11160 | • • SCREW | 1 | ||||
| ? | 423-57-11350 | • • SLIDE, L.H | 1 | ||||
| ? | 423-57-11340 | • • SLIDE. R.H | 1 | ||||
| ? | 423-57-11390 | • • BOLT | 4 | ||||
| ? | 423-57-11360 | • • LEVER | 1 | ||||
| ? | 423-54-11410 | • • SCREW | 1 | ||||
| ? | 423-57-11400 | • SUSPENSION ASSEMBLY | 1 | ||||
| ? | 423-57-11530 | • • ADJUSTER, TILT | 1 | ||||
| ? | 423-57-11520 | • • ABSORBER | 1 | ||||
| ? | 423-57-11510 | • • SPRING | 1 | ||||
| ? | 423-57-11630 | • • KNOB | 1 | ||||
| ? | 423-57-11640 | • • PIN, SPRING | 1 | ||||
| ? | 423-57-11130 | • NUT | 4 | ||||
| ? | 423-57-11150 | • WASHER | 4 | ||||
| ? | 01435-01220 | BOLT | 4 | ||||
| ? | 421-57-11141 | REST, ARM | 2 | ||||
| ? | 01435-00820 | BOLT | 4 | ||||
| ? | 01010-51225 | BOLT | 4 | F2 | |||
| ? | 01643-31232 | WASHER | 4 | F2 | |||
| ? | |||||||
| ? | F1 - WHOLE SEAT ASSEMBLY AND SUSPENSION MUST BE | ||||||
| ? | REPLACED, IF CONVERTING TO SEAR'S SEAT PART | ||||||
| ? | NUMBER 423-57-A1100. | ||||||
| ? | |||||||
| ? | F2-BOLT AND WASHER ARE USED AS SET. |
