| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 421-06-12213 | HARNESS, TO INSTRUMENT PANEL & RH CONSOLE BOX | 1 | F1 | |||
| ? | 421-06-12214 | HARNESS, TO INSTRUMENT PANEL & RH CONSOLE BOX | 1 | F2 | |||
| ? | 421-06-12215 | HARNESS, TO INSTRUMENT PANEL & RH CONSOLE BOX | 1 | F3 | |||
| ? | 425-06-12141 | HARNESS, TRANSMISSION | 1 | F4 | |||
| ? | 425-06-12142 | HARNESS, TRANSMISSION | 1 | F5 | |||
| ? | 7819-11-2310 | SENSOR, SPEED | 1 | ||||
| ? | 7861-91-3330 | SENSOR, OIL TEMPERATURE | 1 | ||||
| ? | 421-06-12510 | HARNESS, TO AIR CONDITIONER UNIT | 1 | ||||
| ? | 424-06-12811 | WIRE ASSEMBLY | 1 | ||||
| ? | 08028-12045 | WIRE, GROUND | 1 | ||||
| ? | 01010-51020 | BOLT | 2 | ||||
| ? | 01605-11023 | WASHER | 2 | ||||
| ? | 01643-31032 | WASHER | 2 | ||||
| ? | 421-06-12660 | BRACKET | 1 | ||||
| ? | 421-06-12641 | BRACKET | 1 | ||||
| ? | 01010-51225 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 421-06-12910 | CLIP | 1 | ||||
| ? | 238-06-17130 | CLIP | 1 | ||||
| ? | 283-06-17120 | CLIP | 2 | ||||
| ? | 421-06-12610 | CLIP | 1 | ||||
| ? | 01220-40608 | SCREW | 5 | ||||
| ? | 01643-20608 | WASHER | 5 | ||||
| ? | 421-06-12670 | BRACKET | 2 | ||||
| ? | 01643-31232 | WASHER | 1 | ||||
| ? | 01010-51225 | BOLT | 1 | ||||
| ? | 01643-31232 | WASHER | 1 | ||||
| ? | 421-06-12910 | CLIP | 3 | ||||
| ? | 01220-40608 | SCREW | 3 | ||||
| ? | 01641-20608 | WASHER | 3 | ||||
| ? | 01220-40612 | SCREW | 1 | ||||
| ? | 01641-20608 | WASHER | 1 | ||||
| ? | 419-09-11160 | CLIP | 2 | ||||
| ? | 424-06-12710 | CLIP | 1 | ||||
| ? | 01010-51016 | BOLT | 3 | ||||
| ? | 01643-31032 | WASHER | 3 | ||||
| ? | 08036-03014 | CLIP | 3 | ||||
| ? | 01010-51220 | BOLT | 2 | ||||
| ? | 01643-31232 | WASHER | 2 | ||||
| ? | 08034-00519 | STRAP, TIE | 2 | ||||
| ? | 08036-03014 | CLIP | 1 | F6 | |||
| ? | WIRE ASSEMBLY, FRONT LINE | 1 | F7 | ||||
| ? | |||||||
| ? | F1 - USED ON MACHINES S/N 10411 (A20001) - 10417 (A20007). | ||||||
| ? | |||||||
| ? | F2 - USED ON MACHINES S/N 10418 (A20008) - A20124. | ||||||
| ? | |||||||
| ? | F3 - USED ON MACHINES S/N A20125 AND UP. | ||||||
| ? | |||||||
| ? | F4 - USED ON MACHINES S/N 10411 (A20001) - A20659. | ||||||
| ? | |||||||
| ? | F5 - USED ON MACHINES S/N A20659 AND UP. | ||||||
| ? | |||||||
| ? | F6 - USES BOLT AND WASHER THAT ATTACHES THE RIGHT HAND | ||||||
| ? | CONSOLE TO THE FLOOR FRAME (SEE PARTS AND SERVICE | ||||||
| ? | LETTER A925004 DATED FEB. 6, 1992. | ||||||
| ? | |||||||
| ? | F7 - SEE PARTS BOOK, FORM PEPBA4250106 - FIG. 1511. | ||||||
| ? |
