| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 124-27-00020 | FINAL DRIVE ASS'Y,R.H. | 1 | SN: B20001-B20500 |
|||
| ? | 124-27-51124 | • CASE,R.H. | 1 | SN: B20001-B20500 |
|||
| ? | 124-27-51521 | • COVER,R.H. | 1 | SN: B20001-B20500 |
|||
| ? | 01010-81645 | • BOLT | 12 | SN: B20001-@ |
|||
| ? | 01643-31645 | • WASHER | 12 | SN: B20001-@ |
|||
| ? | 07044-13620 | • PLUG | 1 | SN: B20001-@ |
|||
| ? | 07041-13612 | • PLUG | 1 | SN: B20001-@ |
|||
| ? | 07002-03634 | • O-RING | 2 | SN: B20001-@ |
|||
| ? | 124-27-51510 | • COVER | 1 | SN: B20001-B20500 |
|||
| ? | 01010-81030 | • BOLT | 8 | SN: B20001-B20500 |
|||
| ? | 01643-31032 | • WASHER | 8 | SN: B20001-B20500 |
|||
| ? | 07000-75240 | • O-RING | 1 | SN: B20001-B20500 |
|||
| ? | 124-27-51211 | • PINION | 1 | SN: B20001-@ |
|||
| ? | 124-27-51412 | • BEARING | 1 | SN: B20001-@ |
|||
| ? | 124-27-51420 | • BEARING | 1 | SN: B20001-@ |
|||
| ? | 124-27-51241 | • SPACER | 1 | SN: B20001-@ |
|||
| ? | 124-27-51162 | • CAGE | 1 | SN: B20001-@ |
|||
| ? | 01010-81025 | • BOLT | 4 | SN: B20001-@ |
|||
| ? | 01643-31032 | • WASHER | 4 | SN: B20001-@ |
|||
| ? | 07000-72125 | • O-RING | 1 | SN: B20001-@ |
|||
| ? | 07013-50075 | • SEAL | 1 | SN: B20001-@ |
|||
| ? | 124-27-51221 | • GEAR | 1 | SN: B20001-@ |
|||
| ? | 124-27-51231 | • SHAFT | 1 | SN: B20001-B20500 |
|||
| ? | 124-27-51431 | • BEARING | 1 | SN: B20001-@ |
|||
| ? | 124-27-51441 | • BEARING | 1 | SN: B20001-@ |
|||
| ? | 124-27-51172 | • COVER | 1 | SN: B20001-@ |
|||
| ? | 01010-81230 | • BOLT | 2 | SN: B20001-B20500 |
|||
| ? | 01643-31232 | • WASHER | 2 | SN: B20001-B20500 |
|||
| ? | 195-30-36190 | • O-RING | 1 | SN: B20001-@ |
|||
| ? | 01011-82400 | • BOLT | 1 | SN: B20001-@ |
|||
| ? | 124-27-51250 | • SPACER | 1 | SN: B20001-@ |
|||
| ? | 124-27-51261 | • SPACER | 1 | SN: B20001-@ |
|||
| ? | 423-22-22350 | • WASHER | 1 | SN: B20001-B20500 |
|||
| ? | 14X-27-00100 | • FLOATING SEAL ASS'Y | 1 | SN: B20001-@ |
|||
| ? | 14X-27-00110 | • • SEAL ASS'Y | 1 | SN: B20001-@ |
|||
| ? | ☆ | • • • SEAL | 2 | SN: B20001-@ |
|||
| ? | 14X-27-00120 | • • O-RING ASS'Y | 1 | SN: B20001-@ |
|||
| ? | ☆ | • • • O-RING | 2 | SN: B20001-@ |
|||
| ? | 708-18-12140 | • O-RING | 1 | SN: B20001-@ |
|||
| ? | 124-27-51154 | • SPROCKET | 1 | SN: B20001-B20500 |
|||
| ? | 124-27-51192 | • HUB | 1 | SN: B20001-B20500 |
|||
| ? | 01010-82470 | • BOLT | 13 | SN: B20001-B20500 |
|||
| ? | 01010-82460 | • BOLT | 13 | SN: B20001-B20500 |
|||
| ? | 01643-32460 | • WASHER | 26 | SN: B20001-B20500 |
