| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (124-15-00030) | TRANSMISSION ASS'Y | 1 | SN: B20001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-01A0 TO F2320-13A0. | ||||||
| ? | 23E-15-12241 | • GEAR | 1 | SN: B20001- |
|||
| ? | 124-15-52150 | • SPACER | 1 | SN: B20001-(03247) |
|||
| ? | 124-15-52331 | • CARRIER | 1 | SN: B20001- |
|||
| ? | 113-15-32560 | • WASHER | 6 | SN: B20001- |
|||
| ? | 23E-15-12441 | • GEAR¤ 18 TEETH | 3 | SN: B20001- |
|||
| ? | 113-15-29410 | • BEARING | 3 | SN: B20001- |
|||
| ? | 124-15-01010 | • SHAFT ASS'Y | 3 | SN: B20001- |
|||
| ? | ☆ | • • SHAFT | 1 | SN: B20001- |
|||
| ? | 145-14-11320 | • • PLUG | 1 | SN: B20001- |
|||
| ? | 124-15-52960 | • PIN,(D= 3.0¤ L= 14.0) | 3 | SN: B20001- |
|||
| ? | 124-15-01020 | • PLATE ASS'Y | 1 | SN: B20001- |
|||
| ? | ☆ | • • PLATE | 1 | SN: B20001- |
|||
| ? | 113-15-25490 | • • PLUG | 1 | SN: B20001- |
|||
| ? | 04020-01024 | • PIN | 2 | SN: B20001- |
|||
| ? | 23E-15-11270 | • PIN,(D=10.0¤ L=232.0) | 5 | SN: B20001- |
|||
| ? | 104-15-22930 | • SPRING,(L= 23.7) | 5 | SN: B20001- |
|||
| ? | 113-15-22640 | • GEAR | 1 | SN: B20001- |
|||
| ? | 124-15-52710 | • DISC | 2 | SN: B20001- |
|||
| ? | 113-15-22720 | • PLATE | 1 | SN: B20001- |
|||
| ? | 113-15-22730 | • PLATE | 2 | SN: B20001- |
|||
| ? | 124-15-51151 | • HOUSING,2ND | 1 | SN: B20001- |
|||
| ? | 103-15-22730 | • PISTON | 1 | SN: B20001- |
|||
| ? | 103-15-29210 | • SEAL (K1) | 1 | SN: B20001- |
|||
| ? | 113-15-29220 | • RING,SEAL (K1) | 1 | SN: B20001- |
|||
| ? | 04020-01024 | • PIN | 2 | SN: B20001- |
