| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 124-15-00030 | TRANSMISSION ASS'Y | 1 | SN: B20001- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-01A0 TO F2320-13A0. | ||||||
| ? | 124-15-52341 | • HOUSING,1ST | 1 | SN: B20001- |
|||
| ? | 124-15-52770 | • PISTON | 1 | SN: B20001- |
|||
| ? | 113-15-29250 | • RING (K1) | 1 | SN: B20001- |
|||
| ? | 103-15-29270 | • SEAL (K1) | 1 | SN: B20001- |
|||
| ? | 06000-06921 | • BEARING | 1 | SN: B20001- |
|||
| ? | 124-15-52390 | • BUSHING | 1 | SN: B20001- |
|||
| ? | 04260-00635 | • BALL | 1 | SN: B20001- |
|||
| ? | 04071-00150 | • RING | 1 | SN: B20001- |
|||
| ? | 01010-80875 | • BOLT | 18 | SN: B20001- |
|||
| ? | 01643-50823 | • WASHER | 18 | SN: B20001- |
|||
| ? | 22W-15-21290 | • PIN,(D=10.0¤ L= 65.0) | 10 | SN: B20001- |
|||
| ? | 04020-01024 | • PIN | 2 | SN: B20001- |
|||
| ? | 124-15-52381 | • CAGE | 1 | SN: B20001- |
|||
| ? | 07018-21155 | • RING | 2 | SN: B20001- |
|||
| ? | 06042-00210 | • BEARING | 1 | SN: B20001- |
|||
| ? | 04065-09030 | • RING | 1 | SN: B20001- |
|||
| ? | 04070-00105 | • RING | 1 | SN: B20001- |
|||
| ? | 124-15-52271 | • HUB | 1 | SN: B20001- |
|||
| ? | 124-15-52710 | • DISC | 3 | SN: B20001- |
|||
| ? | 125-15-32750 | • PLATE | 4 | SN: B20001- |
|||
| ? | 23A-15-12910 | • SPRING,(L= 35.0) | 5 | SN: B20001- |
