| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 426-16-11523 | OIL FILTER ASS'Y | 2 | ||||
| ? | 424-16-11161 | • CASE | 3 | ||||
| ? | 07040-11209 | • PLUG | 3 | ||||
| ? | 07002-11223 | • O-RING | 3 | ||||
| ? | 424-16-11191 | • SPRING | 3 | ||||
| ? | 424-16-11630 | • O-RING | 3 | ||||
| ? | 424-16-11140 | • ELEMENT | 3 | ||||
| ? | 425-16-11282 | • COVER, HEAD | 1 | ||||
| ? | 425-16-11132 | • COVER, HEAD | 2 | ||||
| ? | 425-16-11240 | • PLUG | 6 | ||||
| ? | 07002-13334 | • O-RING | 6 | ||||
| ? | 424-16-11130 | • O-RING | 3 | ||||
| ? | 424-16-11171 | • BOLT | 3 | ||||
| ? | 424-16-11620 | • WASHER | 3 | ||||
| ? | 424-16-11630 | • O-RING | 3 | ||||
| ? | 07000-13038 | • O-RING | 4 | ||||
| ? | 01010-81040 | • BOLT | 12 | ||||
| ? | 01602-21030 | • WASHER, SPRING | 12 | ||||
| ? | 425-16-11260 | • PLATE | 1 | ||||
| ? | 425-16-11270 | • PLATE | 1 | ||||
| ? | 07000-13038 | • O-RING | 2 | ||||
| ? | 01010-81025 | • BOLT | 5 | ||||
| ? | 01010-81040 | • BOLT | 3 | ||||
| ? | 01602-21030 | • WASHER, SPRING | 8 | ||||
| ? | 01580-11008 | • NUT | 3 |
