| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TRANSMISSION ASS'Y (SEE PG 02-022) | -29 | 07DZW800.002 | ||||
| ? | 427-15-13310 | • SHAFT | 1 | ||||
| ? | 427-15-13280 | • SPACER | 1 | ||||
| ? | 427-15-13240 | • GEAR | 1 | ||||
| ? | 427-15-13180 | • CAGE | 1 | ||||
| ? | 06032-00228 | • BEARING | 1 | ||||
| ? | 04071-00250 | • RING, SNAP | 1 | ||||
| ? | 427-15-19110 | • SEAL, OIL | 1 | F1 | |||
| ? | 07000-05410 | • O-RING | 1 | F1 | |||
| ? | 01010-51240 | • BOLT | 8 | ||||
| ? | 01643-31232 | • WASHER | 8 | ||||
| ? | 427-15-13290 | • SPACER | 1 | ||||
| ? | 427-15-13190 | • CAGE | 1 | ||||
| ? | 427-15-19430 | • BEARING | 1 | ||||
| ? | 427-15-19110 | • SEAL, OIL | 1 | F1 | |||
| ? | 07000-05260 | • O-RING | 1 | F1 | |||
| ? | 427-15-13520 | • SHIM, 0.15MM | 10 | F1 | |||
| ? | 427-15-13510 | • SHIM, 0.2MM | 10 | F1 | |||
| ? | 01010-51240 | • BOLT | 6 | ||||
| ? | 01643-31232 | • WASHER | 6 | ||||
| ? | 427-15-13250 | • COUPLING | 1 | ||||
| ? | 427-15-13260 | • COUPLING | 1 | ||||
| ? | 562-15-19970 | • O-RING | 2 | F1 | |||
| ? | 427-15-13270 | • HOLDER | 2 | ||||
| ? | 562-15-13290 | • BOLT | 2 | ||||
| ? | 01643-33690 | • WASHER | 2 | ||||
| ? | 427-15-05011 | SERVICE KIT, TRANSMISSION | 1 | ||||
| ? | |||||||
| ? | F1 - PART OF TRANSMISSION SERVICE KIT 427-15-05011. | ||||||
| ? |
