| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 427-20-11120 | DRIVE SHAFT ASS'Y | 1 | F1,F2 | |||
| ? | 426-20-12530 | • SPIDER ASS'Y | 2 | ||||
| ? | 426-20-12540 | • FITTING, GREASE | 2 | ||||
| ? | 426-20-14540 | • FITTING, GREASE | 2 | ||||
| ? | 426-20-12550 | • BOLT | 8 | ||||
| ? | 427-20-11520 | • YOKE AND SHAFT A | 1 | ||||
| ? | (NSS) | • • YOKE | 1 | ||||
| ? | (NSS) | • • SHAFT | 1 | ||||
| ? | 01050-61470 | • BOLT | 8 | ||||
| ? | |||||||
| ? | F1 - USED ON S/N 20014, 20020 AND UP. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - ONLY COMPLETE ASSEMBLY IS INTERCHANGEABLE WITH GREASEABLE ASSEMBLY. | ||||||
| ? |
