| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 427-06-A3111 | SUPPORT, L. H | 1 | ||||
| ? | 427-06-A3121 | SUPPORT, R. H | 1 | ||||
| ? | 01010-81260 | BOLT | 8 | ||||
| ? | 01643-31232 | WASHER | 8 | ||||
| ? | 419-06-13221 | BRACKET, L. H | 1 | ||||
| ? | 419-06-13231 | BRACKET, R. H | 1 | ||||
| ? | 01435-01250 | BOLT | 6 | ||||
| ? | 419-43-17920 | WASHER | 12 | ||||
| ? | 415-64-13130 | CUSHION | 6 | ||||
| ? | 419-43-17930 | CUSHION | 6 | ||||
| ? | 417-62-14130 | SPACER | 6 | ||||
| ? | 08037-03614 | GROMMET | 2 | ||||
| ? | 421-06-13102 | LAMP ASS'Y, HEAD | 2 | ||||
| ? | 421-06-13110 | • BULB, 85/65W | 1 | ||||
| ? | 421-06-13120 | • CUSHION | 4 | ||||
| ? | 419-06-13250 | COVER | 2 | ||||
| ? | 01220-40610 | SCREW | 8 | ||||
| ? | 01602-20619 | WASHER, SPRING | 8 | ||||
| ? | 421-06-13301 | LAMP ASS'Y, R. H | 1 | ||||
| ? | 421-06-13401 | LAMP ASS'Y, L. H | 1 | ||||
| ? | 22W-06-12310 | • LENS, L. H | 1 | ||||
| ? | 22W-06-12320 | • LENS, R. H | 1 | ||||
| ? | 421-06-13310 | • BULB, 10/4W | 1 | ||||
| ? | 08105-12420 | • BULB, 25W | 2 | ||||
| ? | 01220-50450 | • SCREW | 2 | ||||
| ? | 01220-50416 | • SCREW | 2 | ||||
| ? | 01641-40405 | • WASHER | 4 | ||||
| ? | 01220-40516 | SCREW | 8 | ||||
| ? | 01601-20513 | WASHER, SPRING | 8 | ||||
| ? | 419-06-13241 | COVER | 2 | ||||
| ? | 01220-40610 | SCREW | 8 | ||||
| ? | 01602-20619 | WASHER, SPRING | 8 |
