Содержание Backhoeloaders Komatsu WB150PS-2N S/N A70001-A70009(WB150P2N)
FIG. A0501-02A0 COOLING WATER SYSTEM(A-034 : A0501-02A0)
Номер на схеме Каталожный номер Название Количество Детали
? TURBO ENGINE(SEE FIG. A0106-02A0) A0106-02A0
? YM129466-49300 • UNION, ELBOW 1
? YM123900-42000 • PUMP ASSEMBLY 1
? YM23871-030000 • • PLUG 2
? YM24311-000400 • • O-RING 1
? YM123900-42110 • GASKET 1
? YM26106-080252 • BOLT 1
? YM26106-080602 • BOLT 4
? YM123900-42450 • PULLEY 1
? YM123900-42480 • V-BELT 1
? YM123900-44731 • FAN 1
? YM123910-44770 • SPACER 1
? YM26106-100452 • BOLT 4
? YM124610-48620 • THERMOSTAT 1
? YM124610-49290 • GASKET 1
? YM123910-49530 • COVER 1
? YM123500-49550 • GASKET 1
? YM26106-080702 • BOLT 4
? YM23000-025000 • CLAMP 4
? YM123910-49032 • TUBE 1
? YM123910-49600 • TUBE 1
? YM123910-49610 • • PROTECTION 1
? YM121450-42450 • PLUG 1
? YM121250-44901 • SWITCH 1
? YM124465-44950 • GASKET 1
? YM124465-44950 • GASKET 1
? YM121851-11970 • UNION 1
