| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 136 276 | CYLINDER ASSEMBLY, SCARIFIER - L.H | 1 | ||||
| ? | 136 277 | CYLINDER ASSEMBLY, SCARIFIER - R.H | 1 | ||||
| ? | 136 279 | • ROD WELDMENT, PISTON | 1 | ||||
| ? | 100 451 | • RING, CLAMP | 1 | ||||
| ? | 403 460 R1 | • WIPER, ROD | 1 | F1 | |||
| ? | 162 899 | • KIT, CYLINDER HEAD REPLACEMENT | 1 | ||||
| ? | 135 274 | • • RING, SEAL RETAINING | 1 | ||||
| ? | 71 900 | • PACKING, ROD | 1 | F1 | |||
| ? | 65 985 | • RING, BACK-UP | 1 | F1 | |||
| ? | 354 836 R1 | • O-RING | 1 | F1 | |||
| ? | 114 730 | • RETAINER, PISTON SEAL | 2 | ||||
| ? | 350 818 R1 | • O-RING | 1 | F1 | |||
| ? | 115 200 | • PACKING, PISTON | 2 | F1 | |||
| ? | 114 728 | • PISTON | 1 | ||||
| ? | 1285 860 H1 | • NUT, LOCK | 1 | ||||
| ? | 136 274 | • CYLINDER WELDMENT - L.H | 1 | ||||
| ? | 136 275 | • CYLINDER WELDMENT - R.H | 1 | ||||
| ? | |||||||
| ? | F1 - INCLUDED IN THE FOLLOWING: | ||||||
| ? | 1279 393 H91 | • KIT, CYLINDER SEAL | 1 |
