| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1253 153 H92 | MOTOR, CRANKING | 1 | ||||
| ? | (NSS) | • WICK, OIL RESERVE | 1 | F2 | |||
| ? | (NSS) | • CUP, OIL RESERVE | 1 | F2 | |||
| ? | (NSS) | • BUSHING, DRIVE HOUSING | 1 | F2 | |||
| ? | 1267 948 H1 | • HOUSING, DRIVE | 1 | ||||
| ? | 1245 105 H1 | • BOLT, DRIVE HOUSING | 3 | ||||
| ? | (NSS) | • STOP, PINION | 1 | F2,F3 | |||
| ? | (NSS) | • RING, RETAINING - PINION STOP | 1 | F2,F3 | |||
| ? | 1210 067 H1 | • DRIVE ASSEMBLY | 1 | ||||
| ? | (NSS) | • WASHER, BRAKE | 1 | F2 | |||
| ? | (NSS) | • O-RING | 1 | F2,F3 | |||
| ? | 1283 447 H1 | • SWITCH, SOLENOID | 1 | ||||
| ? | 1283 448 H1 | • BOLT & WASHER - SWITCH ATTACHING | 3 | ||||
| ? | (NSS) | • O-RING | 1 | F2,F3 | |||
| ? | 1228 450 H1 | • PLUNGER | 1 | ||||
| ? | 1210 070 H1 | • WASHER, PLUNGER SPRING RETAINER | 1 | ||||
| ? | 1210 071 H1 | • BOOT | 1 | ||||
| ? | 1210 072 H1 | • RETAINER, PLUNGER SPRING | 1 | ||||
| ? | 1210 073 H1 | • SPRING, PLUNGER | 1 | ||||
| ? | 1210 074 H1 | • RETAINER, PLUNGER SPRING | 1 | ||||
| ? | 213 262 R1 | • RING, RETAINING | 1 | ||||
| ? | 1210 066 H1 | • PLUG, INSPECTION - LEVER HOUSING | 1 | ||||
| ? | 1211 151 H1 | • GASKET, INSPECTION PLUG | 1 | F2,F3 | |||
| ? | (NSS) | • NUT | 1 | F2,F3 | |||
| ? | (NSS) | • WICK, OIL RESERVE | 1 | F2 | |||
| ? | (NSS) | • CUP, OIL RESERVE | 1 | F2 | |||
| ? | (NSS) | • RING, RETAINING | 1 | F3 | |||
| ? | (NSS) | • BUSHING, LEVER HOUSING | 1 | F2 | |||
| ? | 352 219 R1 | • O-RING | 1 | F3 | |||
| ? | (NSS) | • SHAFT, SHIFT LEVER | 1 | F3 | |||
| ? | (NSS) | • LEVER, SHIFT | 1 | F3 | |||
| ? | 355 967 R1 | • O-RING | 1 | F3 | |||
| ? | 1268 221 H1 | • SHOE, POLE | 4 | ||||
| ? | 1245 108 H1 | • SCREW, POLE SHOE | 8 | ||||
| ? | 1283 445 H1 | • FIELD COIL | 1 | ||||
| ? | 1211 292 H1 | • SCREW | 2 | ||||
| ? | 1210 065 H1 | • ARMATURE | 1 | ||||
| ? | 1283 448 H1 | • BOLT & WASHER - CONNECTOR TO FIELD TERMINAL | 1 | ||||
| ? | 1283 456 H1 | • CONNECTOR - FIELD TERMINAL TO SWITCH | 1 | ||||
| ? | 1210 062 H1 | • INSULATOR, FIELD TERMINAL (OUTSIDE) FRAME | 1 | ||||
| ? | 1210 061 H1 | • INSULATOR, FIELD TERMINAL (INSIDE) FRAME | 1 | ||||
| ? | 1283 448 H1 | • BOLT & WASHER | 1 | ||||
| ? | (NSS) | • WASHER, THRUST | 1 | F2 | |||
| ? | 1283 452 H1 | • PLATE ASSEMBLY, BRUSH | 1 | ||||
| ? | (NSS) | • SPRING, BRUSH | 1 | F1 | |||
| ? | 1228 454 H1 | • PIN, SPRING - BRUSH PLATE LOCATOR | 1 | ||||
| ? | (NSS) | • BRUSH | 1 | F1 | |||
| ? | 1211 292 H1 | • SCREW, BRUSH ATTACHING | 1 | F1 | |||
| ? | 1228 453 H1 | • INSULATOR | 1 | ||||
| ? | (NSS) | • WASHER | 1 | F2 | |||
| ? | 22 411 R1 | • O-RING | 1 | F2 | |||
| ? | (NSS) | • SEAL, OIL | 1 | F2 | |||
| ? | 1266 795 H1 | • HOUSING, LEVER | 1 | ||||
| ? | 1245 107 H1 | • BOLT, LEVER HOUSING | 1 | ||||
| ? | (NSS) | • BODY, CRANKING MOTOR | 1 | ||||
| ? | (NSS) | • O-RING | 1 | F1,F2 | |||
| ? | (NSS) | • BUSHING | 1 | F2 | |||
| ? | (NSS) | • CUP, OIL RESERVE | 1 | F2 | |||
| ? | (NSS) | • WICK, OIL RESERVE | 1 | F2 | |||
| ? | 1283 444 H1 | • FRAME | 1 | ||||
| ? | (NSS) | • BOLT & WASHER - FRAME | 4 | F1,F2 | |||
| ? | |||||||
| ? | F1 - INCLUDED IN THE FOLLOWING KIT: | ||||||
| ? | 1283 495 H1 | PACKAGE, 24 VOLT BRUSH | 1 | ||||
| ? | |||||||
| ? | F2 - INCLUDED IN THE FOLLOWING KIT: | ||||||
| ? | 1283 496 H1 | PACKAGE, BUSHING | 1 | ||||
| ? | |||||||
| ? | F3 - INCLUDED IN THE FOLLOWING KIT: | ||||||
| ? | 1268 843 H1 | PACKAGE, SHIFT LEVER | 1 |
