| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PUMP & TRANSFER CASE (SEE PG 10-078) | -29 | 10AR4151.002 | ||||
| ? | 1433 532 H91 | HARNESS, REAR SENSOR | 1 | ||||
| ? | • WIRE - 1 AWD | ||||||
| ? | • WIRE - E AWD | ||||||
| ? | • WIRE - 1 AWD | ||||||
| ? | • WIRE - F AWD | ||||||
| ? | 299 406 C1 | CLAMP | 2 | ||||
| ? | 1246 048 H1 | SENSOR, MAGNETIC PICKUP - REAR | 1 | ||||
| ? | 1259 559 H3 | CONTROLLER, ELECTRONIC | 1 | ||||
| ? | RELAY, REVERSE (SEE PG 08-006) | -29 | 08ADG532.004 | ||||
| ? | 1432 716 H1 | RELAY, AWD DISABLE | 1 | ||||
| ? | 1284 602 H91 | HARNESS, FRONT SENSOR | 1 | ||||
| ? | 25 752 R1 | BOLT | 4 | ||||
| ? | 25 542 R1 | WASHER, LOCK | 4 | ||||
| ? | VALVE, HIC (SEE PG 10-174) | -29 | 10BH4151.011 | ||||
| ? | 386 170 C2 | STRAP, TIE | A/R | ||||
| ? | 1258 753 H1 | SENSOR, MAGNETIC PICKUP - FRONT | 1 | ||||
| ? | 1430 440 H1 | CABLE, JUMPER - FROM AWD FILTER TO HYD. FILTER | 1 |
