| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1432 902 H91 | DIFFERENTIAL, LOCK/UNLOCK | 1 | ||||
| ? | 1432 907 H1 | • BOLT | 12 | ||||
| ? | 1432 908 H1 | • COVER (ALSO ORDER ITEM 3) | 1 | ||||
| ? | 1432 909 H1 | • PIN, SPRING | 3 | ||||
| ? | 1432 910 H1 | • WASHER | 2 | ||||
| ? | 1432 911 H1 | • SPRING | 3 | ||||
| ? | 1432 912 H1 | • DISK | 4 | ||||
| ? | 1432 913 H1 | • PLATE, CLUTCH SEPARATOR | 3 | ||||
| ? | 1432 914 H1 | • PLATE, CLUTCH BACKING | 1 | ||||
| ? | 1432 915 H1 | • HOUSING ASSEMBLY | 1 | ||||
| ? | 1432 818 H1 | • • PISTON | 1 | ||||
| ? | 1432 819 H1 | • • SEAL | 1 | ||||
| ? | 1432 820 H1 | • • SEAL | 1 | ||||
| ? | 1432 821 H1 | • • BUSHING | 1 | ||||
| ? | 1432 822 H1 | • • PACKING | 1 | ||||
| ? | 1431 070 H1 | • BOLT | 12 | ||||
| ? | 1431 071 H1 | • WASHER | 12 | ||||
| ? | 1432 823 H1 | • GEAR, BEVEL | 1 | ||||
| ? | 1432 825 H1 | • WASHER, THRUST | 4 | ||||
| ? | 1432 827 H1 | • WASHER, THRUST | 4 | ||||
| ? | 1432 828 H1 | • ROLLER, NEEDLE | 104 | ||||
| ? | 1432 831 H1 | • PINION | 4 | ||||
| ? | 1432 832 H1 | • WASHER, THRUST | 4 | ||||
| ? | 1432 833 H1 | • RING, RETAINING | 2 | ||||
| ? | 1432 834 H1 | • SHAFT, PINION | 2 | ||||
| ? | 1432 835 H1 | • GEAR, BEVEL | 1 | ||||
| ? | 1432 836 H1 | • HOUSING | 1 | ||||
| ? | 1432 839 H1 | • • BALL | 1 | ||||
| ? | 1432 903 H1 | • • BALL | 1 | ||||
| ? | 1432 799 H1 | • BOLT | 8 | ||||
| ? | 1432 904 H1 | • RING | 2 | ||||
| ? | 1430 206 H91 | GEAR SET, PINION & RING | 1 |
