| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TRANSMISSION . . . . . . . . . . . . . . . . . . . RF | ||||||
| ? | 134 361 | • CASE, MAIN | 1 | ||||
| ? | 20 973 R1 | • PLUG, PIPE | 3 | ||||
| ? | 134 945 | • GASKET, SUCTION SCREEN | 1 | ||||
| ? | 134 937 | • SCREEN, SUCTION | 1 | ||||
| ? | 309 161 R1 | • WASHER, SEAL | 2 | ||||
| ? | 134 395 | • PLUG, EXPANSION | 2 | ||||
| ? | 84 880 | • BOLT | 2 | ||||
| ? | 134 362 | • TUBE, SUCTION | 1 | ||||
| ? | 37 093 | • BOLT | 1 | ||||
| ? | 134 944 | • CLAMP, TUBE | 1 | ||||
| ? | • O-RING - NOT USED | 1 | |||||
| ? | 444 679 | • PLUG, PIPE | 1 | ||||
| ? | 134 358 | • BAFFLE, OIL | 1 | ||||
| ? | 149 491 | • PLUG, PIPE | 2 | ||||
| ? | 82 717 | • BOLT | 2 | ||||
| ? | 38 653 | • PLUG, EXPANSION | 1 | ||||
| ? | 69 890 | • PLUG, EXPANSION | 1 | ||||
| ? | 110 702 | • PLUG, EXPANSION | 1 | ||||
| ? | 17 012 R1 | • BALL | 1 |
