| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TRANSMISSION . . . . . . . . . . . . . . . . . . . RF | ||||||
| ? | 1244 241 H91 | • COVER ASSEMBLY, FRONT | 1 | ||||
| ? | 1270 190 H1 | • • COVER, FRONT | 1 | ||||
| ? | 562 966 C3 | • • VALVE ASSEMBLY, CONVERTER RELIEF | 1 | ||||
| ? | 444 679 | • • PLUG, PIPE | 1 | ||||
| ? | 1277 914 H91 | • • KIT, SERVICE | 1 | ||||
| ? | 1232 272 H1 | • • • GASKET ELIMINATOR 515 - 50 ML TUBE | 1 | ||||
| ? | 149 513 | • • • COVER, OIL PASSAGE | 1 | ||||
| ? | 149 514 | • • • BOLT | 3 | ||||
| ? | 1244 191 H1 | • • SLEEVE, BORE | 3 | ||||
| ? | 149 662 | • • COVER | 1 | ||||
| ? | 149 663 | • • O-RING | 1 | ||||
| ? | 149 463 | • • GEAR, AUXILIARY PUMP | 1 | ||||
| ? | 134 322 | • • SHAFT, IDLER | 1 | ||||
| ? | 1280 248 H1 | • • CUP, BEARING | 2 | ||||
| ? | 149 466 | • • RING, RETAINING | 1 | ||||
| ? | 134 385 | • • WASHER, RETAIN | 1 | ||||
| ? | 25 329 R1 | • • BOLT | 1 | ||||
| ? | 149 476 | • • SPACER, BEARING | 1 | ||||
| ? | 134 386 | • • PIN | 1 | ||||
| ? | 1280 249 H1 | • • CONE, BEARING | 2 | ||||
| ? | 44 159 | • • ELBOW | 1 | ||||
| ? | 135 762 | • • TUBE, LUBE | 1 | ||||
| ? | 134 323 | • • BREATHER | 1 | ||||
| ? | 149 470 | • • TUBE, STATOR SUPPORT | 1 | ||||
| ? | 149 527 | • • PLATE, COVER | 1 | ||||
| ? | 70 019 | • • BOLT | 6 | ||||
| ? | 149 529 | • • WASHER, THRUST | 1 | ||||
| ? | 149 530 | • • GEAR, IMPELLER HUB | 1 | ||||
| ? | 134 875 | • • BEARING | 1 | ||||
| ? | 1431 220 H1 | • • SEAL, OIL | 1 | ||||
| ? | 149 531 | • • GASKET ELIMINATOR 515 - 50 ML TUBE | 1 | ||||
| ? | 149 532 | • • RETAINER, BEARING | 1 | ||||
| ? | 55 603 | • • BOLT | 7 | ||||
| ? | 134 334 | • SHAFT, INPUT | 1 | ||||
| ? | 134 337 H45 | • RETAINER, BEARING | 1 | ||||
| ? | 135 297 | • BOLT | 3 | ||||
| ? | 134 335 | • BEARING, BALL | 1 | ||||
| ? | 70 629 | • RING, RETAINING | 1 | ||||
| ? | 149 524 | • RING, SEAL | 1 |
