Каталог Komatsu

k-part

Номер на схеме	Каталожный номер	Название	Количество
?	1244 220 H91	CLUTCH ASSEMBLY - 3 & 4	1
?	134 354	• DRUM & SHAFT, CLUTCH	1
?	134 340	• PISTON	2
?	1244 203 H1	• RING, SEAL	2
?	1285 981 H1	• RING, BACK-UP	2
?	86 843	• O-RING	2
?	1244 205 H1	• PLATE, CLUTCH	20
?	149 585	• PLATE, SEPARATOR	20
?	1286 674 H1	• RETAINER	2
?	149 587	• RING, RETAINING	2
?	135 784	• SPRING	2
?	134 341	• RETAINER	2
?	123 760	• RING, RETAINING	2
?	134 401	• BEARING	1
?	134 352	• GEAR & HUB ASSEMBLY	1
?	134 403	• BEARING	1
?	149 593	• BEARING	2
?	1234 846 H1	• RING, SEAL	3
?	134 399	• BEARING	2
?	107 771	• RING, RETAINING	2
?	134 353	• GEAR & HUB ASSEMBLY	1
?	134 387	• RING, RETAINING	1
