| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1281 326 H91 | FILTER, CONVERTER OIL | 1 | ||||
| ? | (NSS) | • HEAD, FILTER | 1 | ||||
| ? | 1267 903 H91 | • INDICATOR ASSEMBLY | 1 | ||||
| ? | 364 839 R1 | • • O-RING | 1 | ||||
| ? | 359 158 R1 | • • O-RING | 1 | ||||
| ? | 1281 327 H1 | • ELEMENT, CONVERTER OIL FILTER | 1 | ||||
| ? | 1279 098 H3 | BRACKET, FILTER MOUNTING | 1 | ||||
| ? | 24 839 R1 | BOLT | 4 | ||||
| ? | 120 382 | WASHER, LOCK | 4 | ||||
| ? | 140 483 H | BOLT | 2 | ||||
| ? | 25 534 R1 | WASHER, FLAT | 4 | ||||
| ? | 25 522 R1 | NUT, HEX | 2 | ||||
| ? | 159 358 | SCREW, MACHINE | 2 | ||||
| ? | 1436 594 H1 | SWITCH, WARNING DELAY | 1 | ||||
| ? | 131 014 | WASHER, FLAT | 2 | ||||
| ? | 131 044 | WASHER, LOCK | 2 | ||||
| ? | 134 530 | NUT, HEX | 2 | ||||
| ? | HARNESS, MAIN WIRING (SEE PG 08-002) | -29 | 08ADG532.001 |
