Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
1278 285 H91 |
TRANSMISSION & TORQUE CONVERTER |
1 |
|
|
|
|
? |
|
• CONVERTER ASSEMBLY (SEE PG 07-010) |
-29 |
|
07AZG8II.001 |
|
|
? |
|
• COVER, FRONT (SEE PG 07-032) |
-29 |
|
07DZG8II.001 |
|
|
? |
25 285 R1 |
• BOLT |
1 |
|
|
|
|
? |
44 855 |
• BOLT |
1 |
|
|
|
|
? |
149 560 |
• BUSHING, LOCATING |
2 |
|
|
|
|
? |
33 368 H45 |
• BOLT |
3 |
|
|
|
|
? |
|
• PUMP, CHARGE (SEE PG 07-022) |
-29 |
|
07BRG8II.001 |
|
|
? |
285 253 R1 |
• O-RING |
1 |
|
|
|
|
? |
1270 488 H1 |
• PLATE, COVER - STAMPED |
1 |
|
|
|
|
? |
81 103 |
• BOLT |
4 |
|
|
|
|
? |
120 384 |
• WASHER, LOCK |
4 |
|
|
|
|
? |
|
• CLUTCH PACK - 1 & 5 (SEE PG 07-024) |
-29 |
|
07CZG8II.001 |
|
|
? |
|
• CLUTCH PACK - 2 & 6 (SEE PG 07-026) |
-29 |
|
07CZG8II.002 |
|
|
? |
|
• CLUTCH PACK - 3 & 4 (SEE PG 07-028) |
-29 |
|
07CZG8II.003 |
|
|
? |
1244 228 H1 |
• GASKET |
1 |
|
|
|
|
? |
89 213 |
• BOLT |
1 |
|
|
|
|
? |
|
• CASE ASSEMBLY, MAIN (SEE PG 07-036) |
-29 |
|
07DZ3959.002 |
|
|
? |
138 296 |
• BOLT |
3 |
|
|
|
|
? |
25 329 R1 |
• BOLT |
1 |
|
|
|
|
? |
149 473 |
• WASHER |
1 |
|
|
|
|
? |
24 864 R1 |
• BOLT |
1 |
|
|
|
|
? |
149 506 |
• O-RING |
1 |
|
|
|
|
? |
134 360 |
• YOKE |
1 |
|
|
|
|
? |
75 991 |
• SEAL, OIL |
1 |
|
|
|
|
? |
25 496 R1 |
• BOLT |
6 |
|
|
|
|
? |
134 359 |
• RETAINER, BEARING |
1 |
|
|
|
|
? |
134 394 |
• O-RING |
1 |
|
|
|
|
? |
|
• SHAFT, OUTPUT (SEE PG 07-030) |
-29 |
|
07DR3959.001 |
|
|
? |
119 859 |
• O-RING |
1 |
|
|
|
|
? |
134 363 |
• KIT, SHIM |
1 |
|
|
|
|
? |
134 364 |
• • SHIM - 0.005 |
3 |
|
|
|
|
? |
134 365 |
• • SHIM - 0.007 |
4 |
|
|
|
|
? |
134 366 |
• • SHIM - 0.020 |
3 |
|
|
|
|
? |
134 380 |
• RETAINER, BEARING |
1 |
|
|
|
|
? |
33 368 H45 |
• BOLT |
4 |
|
|
|
|
? |
|
• VALVE, CONTROL (SEE PG 07-038) |
-29 |
|
07EMG8II.001 |
|
|
? |
135 297 |
• BOLT |
12 |
|
|
|
|
? |
1244 194 H1 |
• RING |
1 |
|
|
|
|
? |
1244 192 H1 |
• PLATE, DRIVE |
3 |
|
|
|
|
? |
1244 193 H1 |
• PLATE ASSEMBLY, CONVERTER DRIVE |
1 |
|
|
|
