| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1280 259 H91 | WHEEL | 4 | F1 | |||
| ? | 96 896 | PLUG, THREAD PROTECTION | 24 | ||||
| ? | 86 784 | BOLT, RIBBED NECK | 32 | ||||
| ? | 110 748 | CLAMP, RIM | 32 | ||||
| ? | 10 790 | NUT, HEX | 32 | ||||
| ? | |||||||
| ? | |||||||
| ? | 1278 226 H91 | TIRE & RIM ASSEMBLY - 17.50 R25 | 6 | ||||
| ? | 91 290 | • RIM ASSEMBLY - 14 X 25 | 1 | ||||
| ? | 91 291 | • • RIM WELDMENT | 1 | ||||
| ? | 128 759 | • • RING, SIDE | 1 | ||||
| ? | 128 760 | • • RING, LOCK | 1 | ||||
| ? | 67 693 | • O-RING | 1 | ||||
| ? | 1278 227 H1 | • TIRE - 17.50 R25 | 1 | F2 | |||
| ? | 159 111 | • STEM, VALVE | 1 | ||||
| ? | 159 112 | • ADAPTOR & CAP | 1 | ||||
| ? | 1433 027 H91 | TIRE & RIM ASSEMBLY - 15.50 R25 | 6 | ||||
| ? | 162 432 | • RIM WELDMENT - 12 X 25 | 1 | ||||
| ? | 162 434 | • RING, SIDE | 1 | ||||
| ? | 128 760 | • RING, LOCK | 1 | ||||
| ? | 67 693 | • 0-RING | 1 | ||||
| ? | 1433 026 H1 | • TIRE - 15.50 R25 | 1 | F2 | |||
| ? | 159 111 | • STEM, VALVE | 1 | ||||
| ? | 1278 224 H91 | TIRE & RIM ASSEMBLY - 14.00 R24 | 6 | ||||
| ? | 91 277 | • RIM ASSEMBLY - 10 X 24 | 1 | ||||
| ? | 91 278 | • • RIM WELDMENT | 1 | ||||
| ? | 91 279 | • • RING, SIDE | 1 | ||||
| ? | 91 280 | • • RING, LOCK | 1 | ||||
| ? | 66 428 | • 0-RING | 1 | ||||
| ? | 1278 225 H91 | • TIRE - 14.00 R24 | 1 | F2 | |||
| ? | 69 440 | • STEM, VALVE | 1 | ||||
| ? | 1433 183 H91 | TIRE & RIM ASSEMBLY - 13.00 R24 | 6 | ||||
| ? | 91 273 | • RIM ASSEMBLY - 8 X 24 | 1 | ||||
| ? | 91 274 | • • RIM WELDMENT | 1 | ||||
| ? | 91 275 | • • RING, SIDE | 1 | ||||
| ? | 91 276 | • • RING, LOCK | 1 | ||||
| ? | 66 428 | • 0-RING | 1 | ||||
| ? | 1433 182 H1 | • TIRE - 13.00 R24 | 1 | F2 | |||
| ? | 69 440 | • STEM, VALVE | 1 | ||||
| ? | |||||||
| ? | F1 - FOR FRONT AXLE WHEEL, | ||||||
| ? | SEE PG 14-005, 9, 019, 25 | ||||||
| ? | |||||||
| ? | F2 - PURCHASE LOCALLY | ||||||
| ? |
