| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1439 969 H91 | ALTERNATOR ASSEMBLY - 24 V, 50 A | 1 | F1 | |||
| ? | 1213 268 H1 | • BEARING | 1 | ||||
| ? | 1218 115 H1 | • REGULATOR | 1 | ||||
| ? | 1307 328 H1 | • RECTIFIER BRIDGE ASSEMBLY | 1 | ||||
| ? | 1307 334 H1 | • CAPACITOR | 1 | ||||
| ? | 1307 576 H1 | • FAN | 1 | ||||
| ? | 1310 140 H1 | • STATOR ASSEMBLY | 1 | ||||
| ? | 1440 072 H1 | • HOUSING, RECTIFIER END | 1 | ||||
| ? | 1440 073 H1 | • BEARING, RECTIFIER END | 1 | ||||
| ? | 1440 074 H1 | • HOUSING, DRIVE END | 1 | ||||
| ? | 1440 075 H1 | • DIODE TRIO | 1 | ||||
| ? | 1440 076 H1 | • COIL, FIELD | 1 | ||||
| ? | 1440 077 H1 | • ROTOR | 1 | ||||
| ? | 1440 078 H1 | • LEAD, EXTERNAL | 1 | ||||
| ? | 1440 079 H91 | • PACKAGE, OUTPUT TERMINAL | 1 | ||||
| ? | 1440 080 H91 | • PACKAGE, RELAY TERMINAL | 1 | ||||
| ? | 1440 081 H91 | • PACKAGE, INDICATOR LIGHT | 1 | ||||
| ? | 1440 082 H91 | • PACKAGE, HARDWARE | 1 | ||||
| ? | |||||||
| ? | F1 - MOUNTING HARDWARE USE 1 EACH: 24 860 R1 BOLT AND 25 536 R1 | ||||||
| ? | WASHER. |
