| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1200 274 H1 | BATTERY - WARM START | 2 | ||||
| ? | 1234 215 H1 | BATTERY, DRY - COLD START | 2 | ||||
| ? | 476 074 C1 | NUT, BATTERY | 4 | ||||
| ? | 1259 311 H1 | CABLE, BATTERY - POSITIVE | 1 | ||||
| ? | 1234 987 H1 | • BOOT, TERMINAL STUD | 1 | ||||
| ? | 1252 287 H1 | CABLE, BATTERY - NEGATIVE | 1 | ||||
| ? | 1234 987 H1 | • BOOT, TERMINAL STUD | 1 | ||||
| ? | 1439 422 H1 | CABLE, BATTERY - JUMPER | 1 | ||||
| ? | 1234 987 H1 | • BOOT, TERMINAL STUD | 2 | ||||
| ? | 21 335 R1 | BOLT | 1 | ||||
| ? | 390 305 C1 | WASHER, FLAT | 1 | ||||
| ? | 1430 378 H1 | CABLE, GROUND | 1 | ||||
| ? | MOTOR, CRANKING (SEE PG 08-026) | -29 | 08AVG381.001 | ||||
| ? | 1260 592 H1 | CABLE, BATTERY - NEGATIVE | 1 | ||||
| ? | 930 587 C4 | SWITCH, KEY | 1 | ||||
| ? | 110 956 | KEY | 2 |
