| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1200 274 H1 | BATTERY - WARM START | 2 | ||||
| ? | 1234 215 H1 | BATTERY, DRY - COLD START | 2 | ||||
| ? | 476 074 C1 | NUT, BATTERY | 4 | ||||
| ? | 1259 311 H1 | CABLE, BATTERY - POSITIVE | 1 | ||||
| ? | 1234 987 H1 | • BOOT, TERMINAL STUD | 1 | ||||
| ? | 1252 290 H2 | CABLE, BATTERY - NEGATIVE | 1 | F1 | |||
| ? | 1234 987 H1 | • BOOT, TERMINAL STUD | 1 | ||||
| ? | 1439 422 H1 | CABLE, BATTERY - JUMPER | 1 | ||||
| ? | 1234 987 H1 | • BOOT, TERMINAL STUD | 2 | ||||
| ? | 21 335 R1 | BOLT | 1 | ||||
| ? | 390 305 C1 | WASHER, FLAT | 1 | ||||
| ? | 1430 378 H1 | CABLE, GROUND | 1 | ||||
| ? | 109 781 | ROD, BATTERY CLAMP | 3 | ||||
| ? | 149 351 | CLAMP, BATTERY | 1 | ||||
| ? | 25 553 R1 | WASHER, FLAT | 3 | ||||
| ? | 120 382 | WASHER, LOCK | 3 | ||||
| ? | 25 522 R1 | NUT, HEX | 3 | ||||
| ? | MOTOR, CRANKING (SEE PG 08-026) | -29 | 08AVG381.001 | ||||
| ? | 30 046 R1 | BOLT | 3 | ||||
| ? | 30 177 R1 | WASHER, FLAT | 3 | ||||
| ? | 931 833 R1 | BOLT | 1 | ||||
| ? | 25 536 R1 | WASHER | 1 | ||||
| ? | 1434 035 H1 | CABLE - FROM STARTER TO FRAME | 1 | ||||
| ? | 30 527 R1 | BOLT | 1 | ||||
| ? | 25 546 R1 | WASHER | 1 | ||||
| ? | |||||||
| ? | F1 - NOT USED IF MACHINE IS EQUIPPED WITH BATTERY MASTER DISCONNECT | ||||||
| ? | SWITCH. |
