Номер на схеме	Каталожный номер	Название	Количество
?		ALTERNATOR - MODEL 23SI (SEE PG 08-032)	-29	08AZG650.001
?		ALTERNATOR - MODEL 20SI (SEE PG 08-034)	-29	08AZT12C.001
?		ALTERNATOR - MODEL 30SI (SEE PG 08-038)	-29	08AZG381.001
?		ALTERNATOR - MODEL 26SI (SEE PG 08-042)	-29	08AZG530.001
?		SENDING UNIT, ENGINE WATER TEMP. (SEE PG 08-076)	-29	08CDG580.003
?	1437 619 H94	HARNESS, ENGINE WIRING	1
?	299 407 C1	CLAMP, CABLE	1
?	299 404 C1	CLAMP, CLOSED	1
?	299 614 C1	CLAMP, CABLE	1
?	30 041 R1	BOLT	2
?	25 536 R1	WASHER, FLAT	4
?		ELBOW, SPECIAL - 90 DEGREES (SEE PG 08-076)	-29	08CDG580.003
?		MOTOR, CRANKING (SEE PG 08-026)	-29	08AVG381.001
?	30 976 R1	SCREW	3
?		SWITCH, CLUTCH PRESSURE (SEE PG 08-076)	-29	08CDG580.003
?		MAIN WIRING HARNESS - TO REAR (SEE PG 08-006)	-29	08BR381.001
?	141 453 H1	CLAMP, CABLE	2
?	25 536 R1	WASHER, FLAT	2
?	1437 824 H93	HARNESS, MAIN WIRING	1
?	130 096	CLAMP, CABLE	1
?	105 899	STUD, WELD	1
?	25 534 R1	WASHER, FLAT	1
?	25 522 R1	NUT, HEX	1
?		FILTER, CONVERTER OIL (SEE PG 07-014)	-29	07BMG580.001
?	143 142 H1	CLAMP, CABLE	1
?	1207 387 H2	SWITCH, MAGNETIC	1
?	28 448 R1	BOLT	2
?	120 392	WASHER, FLAT	2
?	25 519 R1	NUT, HEX	2
?	1434 203 H1	DIODE	1
?		SENDING UNIT, ENGINE OIL PRESSURE (SEE PG 08-076)	-29	08CDG580.003
?	1137 360 C2	SWITCH, ENGINE WATER TEMPERATURE	1
?	299 565 C1	CLAMP, CABLE	4
?	136 055	CLAMP, CABLE	6
?	105 899	STUD, WELD	10
?	25 534 R1	WASHER, FLAT	17
?	25 522 R1	NUT, HEX	14
?	299 399 C1	CLAMP, CABLE	1
?	37 467	STUD, WELD	3
?	25 532 R1	WASHER, FLAT	9
?	25 519 R1	NUT, HEX	9
?		SENDING UNIT, ARTICULATION (SEE PG 08-078)	-29	08CD3603.002
?
?
