| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1436 893 H91 | SHUTTER ASSEMBLY | 1 | ||||
| ? | 1433 626 H91 | • SPRING | 1 | ||||
| ? | 1440 300 H91 | • KIT, VANE | 19 | ||||
| ? | (NSS) | • • VANE | 1 | ||||
| ? | 1440 301 H1 | • • CRANK, LEFT | 1 | ||||
| ? | 1440 302 H1 | • • CRANK, RIGHT | 1 | ||||
| ? | 1437 645 H1 | • BRACKET AND STUD | 1 | ||||
| ? | 1437 644 H1 | • SCREW | 2 | ||||
| ? | 1440 303 H1 | • WASHER, BRASS | 1 | ||||
| ? | 379 310 R1 | • E-CLIP | 1 | ||||
| ? | • CYLINDER, HYDRAULIC (SEE PG 10-230) | -29 | 10BRG670.002 | ||||
| ? | 25 653 R1 | • BOLT | 2 |
