| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1433 940 H91 | RADIO INSTALLATION | 1 | ||||
| ? | 1431 316 H91 | • RADIO ASSEMBLY, AM/FM STEREO | 1 | F3 | |||
| ? | 1434 714 H1 | • • RADIO | 1 | ||||
| ? | 1434 921 H1 | • • BUSHING, REAR | 1 | ||||
| ? | 1434 717 H1 | • • HOUSING, RADIO/SPEAKER | 1 | ||||
| ? | 1434 718 H1 | • • SPEAKER, 4 IN. DUAL CONE | 2 | ||||
| ? | 1434 719 H1 | • • HARNESS, RADIO WIRING | 1 | ||||
| ? | 1434 715 H1 | • • PLATE, ROOF MOUNTING | 1 | ||||
| ? | 1434 716 H1 | • • BRACKET, REAR SUPPORT | 1 | ||||
| ? | 26 000 R1 | • • SCREW, SHEET METAL | 1 | ||||
| ? | 1434 920 H1 | • • ANTENNA | 1 | ||||
| ? | 187 540 | • GROMMET | 1 | ||||
| ? | 180 048 | • BOLT | 2 | ||||
| ? | 23 323 H | • SPACER | 2 | ||||
| ? | 645 342 C1 | • SPACER - USE WITH SOUND INSULATION | 2 | ||||
| ? | 25 542 R1 | • WASHER, FLAT - USE WITH SOUND INSULATION | 10 | ||||
| ? | 1434 023 H1 | SEALANT, ELECTRIC | 1 | F4 | |||
| ? | |||||||
| ? | F1 - AM/FM CASSETTE STEREO SAME AS ABOVE EXCEPT AS FOLLOWS; | ||||||
| ? | 1433 942 H91 | RADIO INSTALLATION | 1 | ||||
| ? | 1432 603 H91 | • RADIO, AM/FM CASSETTE STEREO | 1 | ||||
| ? | 1434 922 H1 | • • RADIO/CASSETTE | 1 | ||||
| ? | |||||||
| ? | F2 - FOR CONVERTER MOUNTING SEE PG 08-047. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F3 - F1 AND F2 APPLY. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F4 - APPLY TO TERMINALS: FILL FEMALE CONNECTORS ONE-HALF FULL. | ||||||
| ? |
