| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1433 852 H91 | INSTALLATION, CAB VENT | 1 | F2 | |||
| ? | 1433 851 H1 | • ANGLE, GRILLE MOUNTING | 1 | ||||
| ? | 180 020 | • BOLT | 24 | ||||
| ? | 120 392 | • WASHER, PLAIN | 28 | ||||
| ? | 1251 486 H1 | • LOUVER, AIR CIRCULATING | 1 | ||||
| ? | 1433 849 H1 | • BAR, CAB TOP - R.H | 1 | ||||
| ? | 1262 387 H1 | • GASKET, AIR INLET COVER | 2 | ||||
| ? | 1262 386 H1 | • GASKET, AIR INLET COVER | 2 | ||||
| ? | 120 375 | • NUT, HEX | 12 | ||||
| ? | 1433 850 H1 | • BAR, CAB TOP - L.H | 1 | ||||
| ? | 1262 385 H1 | • GASKET, FILTER MOUNTING | 1 | ||||
| ? | 1433 843 H91 | • HOUSING, AIR FILTER | 1 | ||||
| ? | 140 828 | • SEAL - 31 IN | 2 | F1 | |||
| ? | 140 828 | • SEAL - 6 IN | 2 | F1 | |||
| ? | 1249 839 H1 | • FILTER, CAB VENT | 1 | ||||
| ? | 1433 844 H91 | • RETAINER, FILTER | 1 | ||||
| ? | 638 896 C1 | • SEALANT | A/R | ||||
| ? | |||||||
| ? | F1 - CUT FROM BULK SEAL. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - NOT SERVICED. REFERENCE ONLY. | ||||||
| ? |
