| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1433 064 H91 | COMPRESSOR, AIR CONDITIONER | 1 | ||||
| ? | 1437 236 H91 | • CLUTCH ASSEMBLY | 1 | ||||
| ? | 1437 845 H91 | KIT, COMPRESSOR MOUNTING BRACKET | 1 | ||||
| ? | 30 022 R1 | • BOLT | 2 | ||||
| ? | 1437 843 H1 | • MOUNT WELDMENT, COMPRESSOR | 1 | ||||
| ? | 933 965 R1 | • WASHER, LOCK | 5 | ||||
| ? | 30 168 R1 | • NUT, HEX | 2 | ||||
| ? | 30 020 R1 | • BOLT | 3 | ||||
| ? | 120 394 | • WASHER, FLAT | 3 | ||||
| ? | 180 122 | • BOLT | 1 | ||||
| ? | 1432 103 H1 | • TIGHTENER | 1 | ||||
| ? | 120 382 | • WASHER, LOCK | 4 | ||||
| ? | 120 377 | • NUT, HEX | 1 | ||||
| ? | 180 081 | • BOLT | 1 | ||||
| ? | 120 393 | • WASHER, FLAT | 2 | ||||
| ? | 120 214 | • WASHER, LOCK | 1 | ||||
| ? | 120 376 | • NUT, HEX | 1 | ||||
| ? | 1432 101 H1 | • BELT | 1 | ||||
| ? | 1432 102 H1 | • PULLEY | 1 | ||||
| ? | 1430 894 H1 | SPACER, FAN | 1 | ||||
| ? | FAN, SUCTION (SEE PG 06-004) | -29 | 06ARG381.001 | ||||
| ? | 30 183 R1 | WASHER, FLAT | 4 | ||||
| ? | 931 628 R1 | BOLT, LOCKING | 4 |
