| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20 537 R1 | BOLT - INSIDE HEATER BOX TO FLOOR PLATE | 7 | ||||
| ? | 28 422 R1 | WASHER, FLAT | 7 | ||||
| ? | BOX ASSEMBLY, HEATER (SEE PG 13-126) | -29 | 13DZG581.001 | ||||
| ? | BOX ASSEMBLY, HEATER (SEE PG 13-128) | -29 | 13DZG530.001 | ||||
| ? | 1435 669 H1 | • HARNESS, HEATER | 1 | ||||
| ? | 1433 882 H1 | GASKET, HEATER | 1 | ||||
| ? | 1434 481 H1 | GASKET, FLOOR PLATE | 1 | ||||
| ? | 104 696 | ADHESIVE - 1 QUART | 1 |
