| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1434 796 H91 | SOUND INSULATION INSTALLATION | 1 | ||||
| ? | 1434 795 H1 | • INSULATION, TOP FRONT | 1 | ||||
| ? | 1434 823 H91 | • COVER, REAR WIPER MOTOR | 1 | ||||
| ? | 180 016 | • BOLT | 4 | ||||
| ? | 120 392 | • WASHER, FLAT | 4 | ||||
| ? | 1433 743 H1 | • BRACKET, REAR COVER MOUNTING | 1 | ||||
| ? | 180 120 | • BOLT | 2 | ||||
| ? | 120 394 | • WASHER, FLAT | 2 | ||||
| ? | 1434 790 H1 | • INSULATION, REAR PANEL - R.H | 1 | ||||
| ? | 1434 791 H1 | • INSULATION, REAR PANEL - L.H | 1 | ||||
| ? | 1434 808 H1 | • INSULATION, REAR PANEL | 1 | ||||
| ? | 1434 794 H1 | • INSULATION, SIDE REAR | 2 | ||||
| ? | 1434 789 H1 | • INSULATION, DOOR HEADER - L.H | 1 | ||||
| ? | 1434 788 H1 | • INSULATION, DOOR HEADER - R.H | 1 | ||||
| ? | 1434 792 H1 | • INSULATION, FRONT - R.H | 1 | ||||
| ? | 1434 793 H1 | • INSULATION, FRONT - L.H | 1 | ||||
| ? | 104 696 C1 | • ADHESIVE | A/R | ||||
| ? | 1253 410 H1 | • PLATE, DEFROSTER FAN BASE | 1 | ||||
| ? | 120 392 | • WASHER, PLAIN | 4 | ||||
| ? | 180 016 | • BOLT | 4 | ||||
| ? | 1434 814 H91 | FLOOR MAT INSTALLATION | 1 | ||||
| ? | 1434 813 H1 | • MAT, FLOOR - TOP | 1 | ||||
| ? | 1433 926 H1 | • MAT, FLOOR - BOTTOM | 1 |
