Номер на схеме	Каталожный номер	Название	Количество
?	1433 721 H94	CAB ASSEMBLY	1
?		• FAN, DEFROSTER (SEE PG 13-160)	-29	13FHG580.001
?	180 020	• BOLT	4
?	120 392	• WASHER, FLAT	4
?	1259 658 H91	• COVER - L.H	1
?	180 020	• BOLT	8
?	120 392	• WASHER, FLAT	8
?	1283 152 H1	• PLUG, STEM BUMPER	8
?		• MOTOR ASSEMBLY, WINDSHIELD WIPER (SEE PG 13-112)	-29	13DHP809.001
?	181 561	• BOLT	2
?	120 392	• WASHER, FLAT	2
?	25 547 R1	• WASHER, FLAT	4
?	130 999	• WASHER, FLAT	2
?		• MIRROR (SEE PG 13-162)	-29	13FR4151.001
?	432 442	• PLUG, BUTTON - 0.468 IN	4
?		• DOOR - L.H. (SEE PG 13-072)	-29	13CMG650.007
?	1434 776 H91	• COVER, FRONT WIPER MOTOR	1
?	24 539 R1	• PLUG, BUTTON - 1 IN	1
?	180 016	• BOLT	4
?	120 392	• WASHER, FLAT	4
?	1268 936 H1	• FASTENER, RATCHET	6
?	1437 043 H1	• GROMMET, TOP LIGHTS	2
?	1259 657 H91	• COVER - R.H	1
?	1139 538 C1	• BOLT, LATCH	2
?	359 783 C1	• NUT	2
?	1268 936 H1	• FASTENER, RATCHET	16
?	1439 477 H91	• CAB WELDMENT	1
?	1433 062 H1	• ANGLE, UPPER SIDE - AIR RECIRCULATION	2
?		• DOOR - R.H. (SEE PG 13-076)	-29	13CMG650.006
?	359 783 C1	• NUT, LOCK - HINGE PIN	2
?	1437 312 H1	• SEAL, DOOR - 96.5 IN	2
?	1437 313 H1	• SEAL, DOOR - HINGE SIDE - 67.5 IN	2
?	1262 235 H1	• TRIM, EDGE - HINGE SIDE - 60 IN	2
?	1251 075 H1	• SEAL DOOR - 22.5 IN	2
?	1262 660 H1	• TRIM, EDGE - 2.1 IN	2
?	1262 660 H1	• TRIM, EDGE - 3 IN	2
?	1262 660 H1	• TRIM, EDGE - 4 IN	4
?	1435 988 H1	• FASTENER, RATCHET	2
?	432 613	• PLUG, BUTTON - 1.06 IN	2
?	1434 778 H1	• COVER	1
?	180 016	• BOLT	3
?	120 392	• WASHER, FLAT	3
?	1437 454 H1	• BUMPER, SOFT	2
?	82 163	• NUT, HEX	2
?	1431 476 H1	• BUMPER, HARD	2
?	82 163	• NUT, HEX	2
?	149 149	• SEAL - 11.91 IN	1
?	104 696	• ADHESIVE, RUBBER	A/R
?		PLATE, FLOOR (SEE PG 12-032)	-29	12BVP809.002
?	180 124	BOLT	8
?		BOX ASSEMBLY, SEAT (SEE PG 13-046)	-29	13CDG530.002
?		BOX ASSEMBLY, HEATER (SEE PG 13-126)	-29	13DZG581.001
?		BOX ASSEMBLY, HEATER (SEE PG 13-128)	-29	13DZG530.001
?		BOX ASSEMBLY, AIR CONDITIONER/HEATER (SEE PG 13-138)		13DZG582.001
?		BOX ASSEMBLY, AIR CONDITIONER/HEATER (SEE PG 13-140)		13DZG530.003
?	1438 322 H91	STRIKER LOOP	2
?	598 813 R1	BOLT, CARRIAGE	2
?	359 787 C1	NUT	2
?	120 396	WASHER, PLAIN	2
?	21 780 R1	SCREW	2
?	120 377	NUT	2
?	120 394	WASHER, FLAT	6
?	1436 675 H91	• HARNESS, CAB WIRING	1
?	299 415 C1	• CLAMP, CABLE	2
?	120 375	• NUT, HEX	2
?	1433 929 H1	• BASE, CABLE TIE MOUNT	5
?	08034-20519	• TIE, CABLE	5
?	1433 790 H1	• HOOK, COAT	1
?	23 979 R1	• SCREW, MACHINE	2
?	1435 518 H91	• MOUNT WELDMENT, DOCUMENT CASE	1
