| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1433 721 H93 | CAB ASSEMBLY | 1 | ||||
| ? | • FAN, DEFROSTER (SEE PG 13-160) | -29 | 13FHG580.001 | ||||
| ? | 180 020 | • BOLT | 4 | ||||
| ? | 120 392 | • WASHER, FLAT | 4 | ||||
| ? | 1259 658 H91 | • COVER - L.H | 1 | ||||
| ? | 180 020 | • BOLT | 8 | ||||
| ? | 120 392 | • WASHER, FLAT | 8 | ||||
| ? | 1283 152 H1 | • PLUG, STEM BUMPER | 8 | ||||
| ? | • MOTOR ASSEMBLY, WINDSHIELD WIPER (SEE PG 13-112) | -29 | 13DHP809.001 | ||||
| ? | 181 561 | • BOLT | 2 | ||||
| ? | 120 392 | • WASHER, FLAT | 2 | ||||
| ? | 25 547 R1 | • WASHER, FLAT | 4 | ||||
| ? | 130 999 | • WASHER, FLAT | 2 | ||||
| ? | • MIRROR (SEE PG 13-162) | -29 | 13FR4151.001 | ||||
| ? | 432 442 | • PLUG, BUTTON - 0.468 IN | 4 | ||||
| ? | • DOOR - L.H. (SEE PG 13-064) | -29 | 13CMG650.003 | ||||
| ? | 359 783 C1 | • NUT, LOCK - HINGE PIN | 2 | ||||
| ? | 1434 776 H91 | • COVER, FRONT WIPER MOTOR | 1 | ||||
| ? | 24 539 R1 | • PLUG, BUTTON - 1 IN | 1 | ||||
| ? | 180 016 | • BOLT | 4 | ||||
| ? | 120 392 | • WASHER, FLAT | 4 | ||||
| ? | 1268 936 H1 | • FASTENER, RATCHET | 6 | ||||
| ? | 1437 043 H1 | • GROMMET, TOP LIGHTS | 2 | ||||
| ? | 1259 657 H91 | • COVER - R.H | 1 | ||||
| ? | 1139 538 C1 | • BOLT, LATCH | 2 | ||||
| ? | 1438 416 H1 | • STUD, STRIKER | 2 | ||||
| ? | 124 829 H1 | • NUT, JAM | 4 | ||||
| ? | 1268 936 H1 | • FASTENER, RATCHET | 16 | ||||
| ? | 1431 817 H91 | • CAB WELDMENT | 1 | ||||
| ? | 1433 062 H1 | • ANGLE, UPPER SIDE - AIR RECIRCULATION | 2 | ||||
| ? | • DOOR - R.H. (SEE PG 13-068) | -29 | 13CMG650.004 | ||||
| ? | 359 783 C1 | • NUT, LOCK - HINGE PIN | 2 | ||||
| ? | 1437 312 H1 | • SEAL, DOOR - 96.5 IN | 2 | ||||
| ? | 1437 313 H1 | • SEAL, DOOR - HINGE SIDE - 67.5 IN | 2 | ||||
| ? | 1262 235 H1 | • TRIM, EDGE - HINGE SIDE - 60 IN | 2 | F1 | |||
| ? | 1251 075 H1 | • SEAL DOOR - 22.5 IN | 2 | ||||
| ? | 1262 660 H1 | • TRIM, EDGE - 2.1 IN | 2 | F1 | |||
| ? | 1262 660 H1 | • TRIM, EDGE - 3 IN | 2 | F1 | |||
| ? | 1262 660 H1 | • TRIM, EDGE - 4 IN | 4 | F1 | |||
| ? | 1435 988 H1 | • FASTENER, RATCHET | 2 | ||||
| ? | 432 613 | • PLUG, BUTTON - 1.06 IN | 2 | ||||
| ? | 1434 778 H1 | • COVER | 1 | ||||
| ? | 180 016 | • BOLT | 3 | ||||
| ? | 120 392 | • WASHER, FLAT | 3 | ||||
| ? | 1437 454 H1 | • BUMPER, SOFT | 2 | ||||
| ? | 82 163 | • NUT, HEX | 2 | ||||
| ? | 1431 476 H1 | • BUMPER, HARD | 2 | ||||
| ? | 82 163 | • NUT, HEX | 2 | ||||
| ? | 149 149 | • SEAL - 11.91 IN | 1 | ||||
| ? | 104 696 | • ADHESIVE, RUBBER | A/R | ||||
| ? | 1433 790 H1 | • HOOK, COAT | 1 | ||||
| ? | 23 979 R1 | • SCREW, MACHINE | 2 | ||||
| ? | 1435 518 H91 | • MOUNT WELDMENT, DOCUMENT CASE | 1 | ||||
| ? | 1436 675 H91 | • HARNESS, CAB WIRING | 1 | ||||
| ? | 299 415 C1 | • CLAMP, CABLE | 2 | ||||
| ? | 120 375 | • NUT, HEX | 2 | ||||
| ? | 1433 929 H1 | • BASE, CABLE TIE MOUNT | 5 | ||||
| ? | 935 522 C1 | • TIE, CABLE | 5 | ||||
| ? | PLATE, FLOOR (SEE PG 12-032) | -29 | 12BVP809.002 | ||||
| ? | 180 124 | BOLT | 8 | ||||
| ? | 25 724 R1 | WASHER, FLAT | 8 | ||||
| ? | BOX ASSEMBLY, SEAT (SEE PG 13-046) | -29 | 13CDG530.002 | ||||
| ? | BOX ASSEMBLY, HEATER (SEE PG 13-126) | -29 | 13DZG581.001 | ||||
| ? | BOX ASSEMBLY, HEATER (SEE PG 13-128) | -29 | 13DZG530.001 | ||||
| ? | BOX ASSEMBLY, AIR CONDITIONER/HEATER (SEE PG 13-138) | 13DZG582.001 | |||||
| ? | BOX ASSEMBLY, AIR CONDITIONER/HEATER (SEE PG 13-140) | 13DZG530.003 | |||||
| ? | |||||||
| ? | F1 - CUT FROM BULK EDGE TRIM. | ||||||
| ? |
