| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1435 040 H92 | CAB ASSEMBLY | 1 | ||||
| ? | 1439 477 H91 | • CAB WELDMENT | 1 | ||||
| ? | 120 391 | • WASHER | 5 | ||||
| ? | 104 696 | • ADHESIVE | 1 | ||||
| ? | 120 392 | • WASHER | 13 | ||||
| ? | 180 020 | • BOLT | 8 | ||||
| ? | 1433 062 H1 | • ANGLE, UPPER SIDE - AIR RECIRCULATION | 2 | ||||
| ? | 1436 675 H91 | • HARNESS, CAB | 1 | ||||
| ? | 180 016 | • SCREW | 1 | ||||
| ? | • MIRROR (SEE PG 13-162) | -29 | 13FR4151.001 | ||||
| ? | 149 149 | • SEAL | 1 | ||||
| ? | 1259 657 H91 | • COVER ASSEMBLY - RIGHT | 1 | ||||
| ? | 1259 658 H91 | • COVER ASSEMBLY - LEFT | 1 | ||||
| ? | 1437 043 H1 | • GROMMET, RUBBER | 1 | ||||
| ? | 1126 558 C1 | • CASE, OPERATOR'S MANUAL | 1 | ||||
| ? | 1129 092 C1 | • CHAIN, BEAD | 1 | ||||
| ? | 1129 094 C1 | • POST SCREW ASSEMBLY | 1 | ||||
| ? | 443 874 | • SCREW | 3 | ||||
| ? | 1434 776 H91 | • COVER, FRONT - WIPER MOTOR | 1 | ||||
| ? | 160 515 | • SCREW, PAN | 4 | ||||
| ? | 24 539 R1 | • PLUG, BUTTON | 1 | ||||
| ? | 274 957 | • SCREW | 2 | ||||
| ? | 120 361 | • NUT | 2 | ||||
| ? | 1262 660 H1 | • EDGE TRIM - 3 IN | 2 | ||||
| ? | 1262 660 H1 | • EDGE TRIM - 2.1 IN | 2 | ||||
| ? | 1262 660 H1 | • EDGE TRIM - 4.0 IN | 4 | ||||
| ? | 1434 778 H1 | • COVER | 1 | ||||
| ? | 1435 518 H91 | • MOUNT, DOCUMENT | 1 | ||||
| ? | 1433 790 H1 | • HOOK, COAT | 1 | ||||
| ? | 23 979 R1 | • SCREW | 2 | ||||
| ? | 299 415 C1 | • CLAMP, CLOSED | 2 | ||||
| ? | 120 375 | • NUT | 2 | ||||
| ? | 1433 929 H1 | • CABLE, TIE MOUNT BASE | 5 | ||||
| ? | 08034-20519 | • CABLE | 5 | ||||
| ? | 1262 660 H1 | • EDGE TRIM - 140 IN | 1 | ||||
| ? | 1262 660 H1 | • EDGE TRIM - 98 IN | 2 | ||||
| ? | 1262 660 H1 | • EDGE TRIM - 153 IN | 2 | ||||
| ? | 1262 660 H1 | • EDGE TRIM - 143 IN | 2 | ||||
| ? | • GLASS, REAR CAB (SEE PG 13-088) | -29 | 13CRG650.001 | ||||
| ? | • SEAL, WINDOW (SEE PG 13-088) | -29 | 13CRG650.001 |
